Samsung VM55B-R 55 inch razor narrow bezel video wall display

Do I Need a Video Wall Controller? Daisy Chain, Processors and LED Controllers

By Trianze Tech Team

Not sure if your video wall needs a controller? Book a site survey or WhatsApp our AV consultants and we will recommend the right video wall setup for your space.

For an LCD video wall that shows one source across all panels, you often do not need a separate controller: many panels can be daisy-chained and set up with their built-in tile matrix, for example up to 5 by 5 on the Samsung VH55C-R and up to 15 by 15 on the LG 55VL5F-A. You need an external video wall processor when the wall must show several sources at once in different windows or switch layouts, as in control rooms. LED walls always need a controller, but all-in-one LED displays have one built in.

Option 1: Daisy Chain and Built-in Tile Matrix

The source connects to the first panel and the signal loops through the rest. Examples from our range:

This suits lobby, retail and presentation walls showing one image, video or playlist across the whole wall.

Option 2: External Video Wall Processor

A processor takes several inputs, such as PCs, cameras and dashboards, and places them in windows anywhere on the wall, with saved layouts operators can switch between. It is the standard choice for control rooms and operations centres. We specify the processor for each project based on the number and type of sources; see our control room solutions.

Option 3: LED Walls and Their Controllers

LED cabinets always need a controller. All-in-one LED displays include it: the Samsung P1.5 130 inch and Samsung P0.84 146 inch have an integrated control box that removes the need for external processors or media players, and the MAXHUB Raptor series has a built-in Android system. Modular walls such as LG MAGNIT connect to a system controller. See our pixel pitch guide.

Which One Do You Need?

Need Recommended setup
One source across the whole LCD wall Daisy chain and built-in tile matrix
Several sources at once, changing layouts External video wall processor
Seamless LED wall All-in-one LED with integrated controller, or modular LED with system controller

Video Walls in Dubai and Abu Dhabi

Trianze Tech designs LCD and LED video walls with the right controller, mounting and calibration, and installs them across the UAE. See our video wall cost factors, the video wall collection and our LED video wall solutions.

Call +971 58 161 3661 | Chat on WhatsApp

Frequently asked questions

Do I need a video wall controller?

Not always. For an LCD video wall that shows one source stretched across all panels, the panels' own daisy chain and tile matrix settings are often enough. You need an external controller or processor when the wall must show several sources at once in different windows, mix resolutions, or switch layouts during operation, as in control rooms.

How big can a daisy-chained video wall be?

It depends on the panel. For example, the Samsung VH55C-R and VH55C-E support daisy chain video walls up to 5 by 5 displays, and the LG 55VL5F-A and 49VL5PJ list tile matrix configurations up to 15 by 15 displays.

Do LED video walls need a controller?

Yes, LED walls always need a controller to drive the LED cabinets. All-in-one LED displays, such as the Samsung P1.5 130 inch and P0.84 146 inch, have an integrated control box, so no separate processor is needed. Modular LED walls such as LG MAGNIT connect to a system controller.

What does daisy chaining mean on a video wall?

Daisy chaining passes the video signal from one display to the next through a loop-out connection, so one source can feed the whole wall without a separate distribution amplifier. LG panels such as the 55VSH7J also support LAN daisy chain for control, monitoring and firmware updates.

What is a video wall processor used for in a control room?

A processor lets operators show many sources at once, such as cameras, dashboards and PCs, in windows of any size across the wall, and switch between saved layouts. It is specified for each control room based on the number and type of sources.

Who supplies and installs video walls and video wall controllers in Dubai and Abu Dhabi?

Trianze Tech supplies, installs and supports video walls and video wall controllers across Dubai, Abu Dhabi and the rest of the UAE, from site survey and design to installation, testing and handover training. Call +971 58 161 3661 or message us on WhatsApp to book a survey.
