LG LAPA136-GF: 136 Inch 1.56mm Pixel Pitch Full HD All-in-One LED Display with Embedded Controller
Model
:
LAPA136-GF
Buying guides for this product
All AV buying guides ›
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
LG LAPA136-GF at a Glance
- Brand
- LG
- Model
- LAPA136-GF
- Category
- Video Wall Displays & Packages
- Solution
- Digital Signage
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
LG LAPA136-GF Overview
The LG LAPA136-GF is an LG all-in-one LED display from the LED Display Series, with a 1.56 mm pixel pitch and Typ. 500 nit brightness. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Pitch Name: P1.56
- Pixel Configuration: Single SMD
- Pixel Pitch: 1.56 mm
- Module Resolution: 192 x 108
- Module Dimensions: 300 x 168.75
- No. of Modules per Screen: 10x10 (Total 100)
Technical Specifications:
| Spec | Value |
|---|---|
| Model | LAPA136-GF |
| Brand | LG |
| Series | LED Display Series |
| Pitch Name | P1.56 |
| Pixel Configuration | Single SMD |
| Pixel Pitch | 1.56 mm |
| Module Resolution | 192 x 108 |
| Module Dimensions | 300 x 168.75 |
| No. of Modules per Screen | 10x10 (Total 100) |
| Screen Resolution | 1,920x1,080 |
| Screen Dimensions | 3,005 X 1,692.5 X 29.95 (Thickest 59.5) |
| Screen Surface Area | 5.06 |
| Weight of the screen | 108.5 |
| Physical Pixel Density | 409,600 pixels/ |
| Flatness of Cabinet | +/-0.15 |
| Cabinet material | Aluminum |
| Service access | Front |
| Brightness | Typ. 500 |
| Color Temperature | 3,200 to 9,300 |
| Visual Viewing Angle | 150 Horizontal |
| Brightness Uniformity | 0.98 |
| Color Uniformity | +/-0.015Cx,Cy |
| Contrast Ratio | 3,000:1 |
| Processing Depth | 16 (HDR10, HDR10 Pro) |
| Power Consumption | 1,300 W/Screen |
| Heat Dissipation | 4,436 BTU/h/Screen |
| Power Supply | 100 to 240 |
| Frame Rate | 50 / 60 Hz |
| Refresh Rate | 3,840 Hz |
| LED Lifetime | 100,000 Half brightness |
| Operating Temperature | 0 to +40 |
| Operating Humidity | 10 to 90%RH |
| IP rating Front | IP30 |
| IP rating Rear | IP30 |
| Certification | CE,FCC,ETL,CB,CE-RED EMC Class A |
| Speaker | Built-in(9W+9W) |
| Environment | RoHS, REACH |
| Controller | Embedded(webOS) |
| I/O Port | HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Digital Audio Out (1, SPDIF Optical) |
| Wi-Fi / BT | Yes / No |
| ETC | IR Remote(In-box), Magic Remote: Not Supported Side by Side: Yes (1xN) HDCP 2.2 Crestron Connected |
Why Buy the LG LAPA136-GF from Trianze Tech?
- Genuine LG LED signage from Trianze Tech, an authorized LG partner, sourced through authorized channels with local UAE support
- Pre-sales help sizing and planning the wall around the LAPA136-GF
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation and content advice for retail, corporate and outdoor projects
What's Included and Support
Frequently asked
LG LAPA136-GF: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The LG LAPA136-GF is an LG all-in-one LED display from the LED Display Series, with a 1.56 mm pixel pitch and Typ. 500 nit brightness. Trianze Tech supplies it in the UAE with project advice.
For the LG LAPA136-GF, LG lists the following. Pixel Pitch: 1.56 mm; Brightness: Typ. 500; Color Temperature: 3,200 to 9,300; Visual Viewing Angle: 150 Horizontal; Brightness Uniformity: 0.98.
For the LG LAPA136-GF, LG lists the following. Module Resolution: 192 x 108; Module Dimensions: 300 x 168.75; No. of Modules per Screen: 10x10 (Total 100); Screen Resolution: 1,920x1,080; Screen Dimensions: 3,005 X 1,692.5 X 29.95 (Thickest 59.5).
For the LG LAPA136-GF, LG lists the following. Power Consumption: 1,300 W/Screen; Heat Dissipation: 4,436 BTU/h/Screen; Power Supply: 100 to 240; Frame Rate: 50 / 60 Hz.
For the LG LAPA136-GF, LG lists the following. Service access: Front; LED Lifetime: 100,000 Half brightness; Operating Temperature: 0 to +40; Operating Humidity: 10 to 90%RH; IP rating Front: IP30.
Trianze Tech stocks the LG LAPA136-GF in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
