LG LSCB015-RK: 1.563mm Pixel Pitch Indoor LED Display Cabinet, Indoor LED Ultra Slim Series
Model
:
LSCB015-RK
Buying guides for this product
All AV buying guides ›
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
LG LSCB015-RK at a Glance
- Brand
- LG
- Model
- LSCB015-RK
- Category
- Video Wall Displays & Packages
- Solution
- Digital Signage
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
LG LSCB015-RK Overview
The LG LSCB015-RK is an LG indoor LED display cabinet from the Indoor LED Ultra Slim Series, with a 1.563 mm pixel pitch and 800 After Calibration nit brightness. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Pixel Configuration: 3 in 1
- Pixel Pitch: 1.563 mm
- Module Resolution: 192 x 108
- Module Dimensions: 300 x 168.75
- Weight per Module: 0.34 (-RK,-CK)/ 0.67 (-CKF)
- No. of Modules per Cabinet: 2x2 (-RK)/ 1x2 (-CK,-CKF)
Technical Specifications:
| Spec | Value |
|---|---|
| Model | LSCB015-RK |
| Brand | LG |
| Series | Indoor LED Ultra Slim Series |
| Pixel Configuration | 3 in 1 |
| Pixel Pitch | 1.563 mm |
| Module Resolution | 192 x 108 |
| Module Dimensions | 300 x 168.75 |
| Weight per Module | 0.34 (-RK,-CK)/ 0.67 (-CKF) |
| No. of Modules per Cabinet | 2x2 (-RK)/ 1x2 (-CK,-CKF) |
| Cabinet Resolution | 384x216 (-RK)/ 192x216 (-CK, -CKF) |
| Cabinet Dimensions | 600x337.5x34 (-RK)/ 300x337.5x29.7 (-CK)/ 300x337.5x35.6 (-CKF, Cabinet Mounting Depth) |
| Cabinet Surface Area | 0.203 (-RK)/ 0.101 (-CK, -CKF) |
| Weight per Cabinet | 5.3 (-RK)/ 4.0 (-CK)/ 3.1 (-CKF, Weight Changes for Different Curves) |
| Weight per Square Meter | 26.2 (-RK)/ 39.0 (-CK)/ 30.6 (-CKF) |
| Physical Pixel Density | 409,600 pixels/m |
| Flatness of Cabinet | +/- 0.1 mm |
| Cabinet Material | Die-casting Aluminum (-RK)/ Aluminum Machine (-CK, CKF) |
| Service Access | Front |
| Maximum brightness | 800 After Calibration |
| Color Temperature | 3,200-9,300 (K) |
| Visual Viewing Angle | 160 x 160 |
| Brightness Uniformity | 97% |
| Color Uniformity | +/- 0.003 Cx,Cy |
| Contrast Ratio | 5,000: 1 |
| Processing Depth | 16(HDR10, HDR10 Pro) |
| Power Consumption | 150 (-RK)/ 75 (-CK, -CKF) |
| Power Supply | 100 to 240 |
| Frame Rate | 50 / 60 Hz |
| Refresh Rate | 3,840 Hz |
| Lifetime | 100,000 Hours to Half Brightness |
| Operating Temperature | -10 degrees to +45 degrees |
| Operating Humidity | 0 to 80 % RH |
| IP rating Front / Rear | IP30 / IP30 |
| Controller | CVCA, LCIN006, LCIN008 (4K) |
| 90 degree corner cut | Yes |
Why Buy the LG LSCB015-RK from Trianze Tech?
- Genuine LG LED signage from Trianze Tech, an authorized LG partner, sourced through authorized channels with local UAE support
- Pre-sales help sizing and planning the wall around the LSCB015-RK
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation and content advice for retail, corporate and outdoor projects
What's Included and Support
Frequently asked
LG LSCB015-RK: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The LG LSCB015-RK is an LG indoor LED display cabinet from the Indoor LED Ultra Slim Series, with a 1.563 mm pixel pitch and 800 After Calibration nit brightness. Trianze Tech supplies it in the UAE with project advice.
For the LG LSCB015-RK, LG lists the following. Pixel Pitch: 1.563 mm; Maximum brightness: 800 After Calibration; Color Temperature: 3,200-9,300 (K); Visual Viewing Angle: 160 x 160; Brightness Uniformity: 97%.
For the LG LSCB015-RK, LG lists the following. Module Resolution: 192 x 108; Module Dimensions: 300 x 168.75; Weight per Module: 0.34 (-RK,-CK)/ 0.67 (-CKF); No. of Modules per Cabinet: 2x2 (-RK)/ 1x2 (-CK,-CKF); Cabinet Resolution: 384x216 (-RK)/ 192x216 (-CK, -CKF).
For the LG LSCB015-RK, LG lists the following. Power Consumption: 150 (-RK)/ 75 (-CK, -CKF); Power Supply: 100 to 240; Frame Rate: 50 / 60 Hz.
For the LG LSCB015-RK, LG lists the following. Service Access: Front; Lifetime: 100,000 Hours to Half Brightness; Operating Temperature: -10 degrees to +45 degrees; Operating Humidity: 0 to 80 % RH; IP rating Front / Rear: IP30 / IP30.
Trianze Tech stocks the LG LSCB015-RK in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
