LG GSEH160-GR: 16mm Pixel Pitch Outdoor LED Display Cabinet, Outdoor Ultra High Brightness LED Series
Model
:
GSEH160-GR
Buying guides for this product
All AV buying guides ›
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
LG GSEH160-GR at a Glance
- Brand
- LG
- Model
- GSEH160-GR
- Category
- Video Wall Displays & Packages
- Solution
- Digital Signage
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
LG GSEH160-GR Overview
The LG GSEH160-GR is an LG outdoor LED display cabinet from the Outdoor Ultra High Brightness LED Series, with a 16 mm pixel pitch and 8,500 nit nit brightness. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Pixel Configuration: Single SMD
- Pixel Pitch: 16.00 mm
- Module Resolution: 12x12
- Module Dimensions: 192x192
- Weight per Module: 0.56 kg
- No. of Modules per Cabinet: 8x8
Technical Specifications:
| Spec | Value |
|---|---|
| Model | GSEH160-GR |
| Brand | LG |
| Series | Outdoor Ultra High Brightness LED Series |
| Pixel Configuration | Single SMD |
| Pixel Pitch | 16.00 mm |
| Module Resolution | 12x12 |
| Module Dimensions | 192x192 |
| Weight per Module | 0.56 kg |
| No. of Modules per Cabinet | 8x8 |
| Cabinet Resolution | 96x96 |
| Cabinet Dimensions | 1,536x1,536x227 |
| Cabinet Surface Area | 2.359 m |
| Weight per Cabinet | 104.0 nit |
| Weight per Square Meter | 44.1 kg/m |
| Physical Pixel Density | 3,906 pixels/m |
| Flatness of Cabinet | +/-1.0 |
| Cabinet Material | Al |
| Service access | Front and Rear |
| Maximum brightness | 8,500 nit |
| Color Temperature | 3,500 to 8,500 |
| Visual Viewing Angle | 160 Horizontal |
| Brightness Uniformity | 97% |
| Color Uniformity | +/-0.05Cx,Cy |
| Contrast Ratio | 10,000:1 |
| Processing Depth | 16 (HDR10, HDR10 Pro) |
| Power Consumption | 1,690 W/Cabinet |
| Heat Dissipation | 5,767 BTU/h/Cabinet |
| Power Supply | 100 to 240 |
| Frame Rate | 50 / 60 Hz |
| Refresh Rate | 3,840 Hz |
| LED Lifetime | 100,000 Half brightness |
| Operating Temperature | -30 C to +50 C |
| Operating Humidity | 0 to 90%RH |
| IP rating Front | IP65 |
| IP rating Rear | IP54 |
| Certification | CE,FCC,ETL |
| Environment | RoHS, REACH |
| Controller | CVEA |
| 90 degree corner cut | Yes |
Why Buy the LG GSEH160-GR from Trianze Tech?
- Genuine LG LED signage from Trianze Tech, an authorized LG partner, sourced through authorized channels with local UAE support
- Pre-sales help sizing and planning the wall around the GSEH160-GR
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation and content advice for retail, corporate and outdoor projects
What's Included and Support
Frequently asked
LG GSEH160-GR: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The LG GSEH160-GR is an LG outdoor LED display cabinet from the Outdoor Ultra High Brightness LED Series, with a 16 mm pixel pitch and 8,500 nit nit brightness. Trianze Tech supplies it in the UAE with project advice.
For the LG GSEH160-GR, LG lists the following. Pixel Pitch: 16.00 mm; Maximum brightness: 8,500 nit; Color Temperature: 3,500 to 8,500; Visual Viewing Angle: 160 Horizontal; Brightness Uniformity: 97%.
For the LG GSEH160-GR, LG lists the following. Module Resolution: 12x12; Module Dimensions: 192x192; Weight per Module: 0.56 kg; No. of Modules per Cabinet: 8x8; Cabinet Resolution: 96x96.
For the LG GSEH160-GR, LG lists the following. Power Consumption: 1,690 W/Cabinet; Heat Dissipation: 5,767 BTU/h/Cabinet; Power Supply: 100 to 240; Frame Rate: 50 / 60 Hz.
For the LG GSEH160-GR, LG lists the following. Service access: Front and Rear; LED Lifetime: 100,000 Half brightness; Operating Temperature: -30 C to +50 C; Operating Humidity: 0 to 90%RH; IP rating Front: IP65.
Trianze Tech stocks the LG GSEH160-GR in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
