LG GSED025-GD: 2.5mm Pixel Pitch Outdoor LED Display Cabinet, Outdoor Eye-Level Accessible LED Series
Model
:
GSED025-GD
Buying guides for this product
All AV buying guides ›
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
LG GSED025-GD at a Glance
- Brand
- LG
- Model
- GSED025-GD
- Category
- Video Wall Displays & Packages
- Solution
- Digital Signage
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
LG GSED025-GD Overview
The LG GSED025-GD is an LG outdoor LED display cabinet from the Outdoor Eye-Level Accessible LED Series, with a 2.5 mm pixel pitch and 4,000 nit nit brightness. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Pixel Configuration: Single SMD
- Pixel Pitch: 2.50 mm
- Module Resolution: 96 x 108
- Module Dimensions: 240 x 270
- Weight per Module: 1.05 kg
- No. of Modules per Cabinet: 2 x 2
Technical Specifications:
| Spec | Value |
|---|---|
| Model | GSED025-GD |
| Brand | LG |
| Series | Outdoor Eye-Level Accessible LED Series |
| Pixel Configuration | Single SMD |
| Pixel Pitch | 2.50 mm |
| Module Resolution | 96 x 108 |
| Module Dimensions | 240 x 270 |
| Weight per Module | 1.05 kg |
| No. of Modules per Cabinet | 2 x 2 |
| Cabinet Resolution | 192 x 216 |
| Cabinet Dimensions | 480 x 540 x 70 |
| Cabinet Surface Area | 0.26 m |
| Weight per Square Meter | 32.7 kg/m |
| Weight per Cabinet | 8.5 kg/cabinet |
| Physical Pixel Density | 160,000 pixels/m |
| Flatness of Cabinet | +/-1.0 mm |
| Cabinet Material | Al |
| Service Access | Front and Rear |
| Visual Viewing Angle | 160 / 140 Horizontal/Vertical |
| Brightness Uniformity | 97% |
| Color Uniformity | +/-0.05 Cx, Cy |
| Contrast Ratio | 4,000: 1 |
| Processing Depth | 16 (HDR10, HDR10 Pro) |
| Maximum brightness | 4,000 nit |
| Color Temperature | 3,500-8,500 |
| Power Consumption | 180 W/cabinet |
| Heat Dissipation | 614 BTU/h/Cabinet |
| Power Supply | 100 to 240 |
| Frame Rate | 50 / 60 Hz |
| Refresh Rate | 3,840 Hz |
| Controller | CVEA |
| LED Lifetime | 100,000 Half Brightness |
| Operating Temperature | -30 to +50 |
| Operating Humidity | 0-90% RH |
| IP rating Front / Rear | IP66 / IP66 |
| Certification | CE / FCC / ETL |
| Environment | RoHS, REACH |
| 90 degree corner cut | Yes |
Why Buy the LG GSED025-GD from Trianze Tech?
- Genuine LG LED signage from Trianze Tech, an authorized LG partner, sourced through authorized channels with local UAE support
- Pre-sales help sizing and planning the wall around the GSED025-GD
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation and content advice for retail, corporate and outdoor projects
What's Included and Support
Frequently asked
LG GSED025-GD: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The LG GSED025-GD is an LG outdoor LED display cabinet from the Outdoor Eye-Level Accessible LED Series, with a 2.5 mm pixel pitch and 4,000 nit nit brightness. Trianze Tech supplies it in the UAE with project advice.
For the LG GSED025-GD, LG lists the following. Pixel Pitch: 2.50 mm; Visual Viewing Angle: 160 / 140 Horizontal/Vertical; Brightness Uniformity: 97%; Contrast Ratio: 4,000: 1; Processing Depth: 16 (HDR10, HDR10 Pro).
For the LG GSED025-GD, LG lists the following. Module Resolution: 96 x 108; Module Dimensions: 240 x 270; Weight per Module: 1.05 kg; No. of Modules per Cabinet: 2 x 2; Cabinet Resolution: 192 x 216.
For the LG GSED025-GD, LG lists the following. Power Consumption: 180 W/cabinet; Heat Dissipation: 614 BTU/h/Cabinet; Power Supply: 100 to 240; Frame Rate: 50 / 60 Hz.
For the LG GSED025-GD, LG lists the following. Service Access: Front and Rear; LED Lifetime: 100,000 Half Brightness; Operating Temperature: -30 to +50; Operating Humidity: 0-90% RH; IP rating Front / Rear: IP66 / IP66.
Trianze Tech stocks the LG GSED025-GD in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
