LG GSCF026-GP: 2.6mm Pixel Pitch Outdoor LED Display Cabinet, Outdoor LED Series
Model
:
GSCF026-GP
Buying guides for this product
All AV buying guides ›
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
LG GSCF026-GP at a Glance
- Brand
- LG
- Model
- GSCF026-GP
- Category
- Video Wall Displays & Packages
- Solution
- Digital Signage
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
LG GSCF026-GP Overview
The LG GSCF026-GP is an LG outdoor LED display cabinet from the Outdoor LED Series, with a 2.6 mm pixel pitch and 5,500 nit nit brightness. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Pixel Configuration: 3 in 1
- Pixel Pitch: 2.6 mm
- Module Resolution: 96 x 96
- Module Dimensions: 250 x 250
- Weight per Module: 0.81 kg
- No. of Modules per Cabinet: 2 x 2
Technical Specifications:
| Spec | Value |
|---|---|
| Model | GSCF026-GP |
| Brand | LG |
| Series | Outdoor LED Series |
| Pixel Configuration | 3 in 1 |
| Pixel Pitch | 2.6 mm |
| Module Resolution | 96 x 96 |
| Module Dimensions | 250 x 250 |
| Weight per Module | 0.81 kg |
| No. of Modules per Cabinet | 2 x 2 |
| Cabinet Resolution | 192 x 192 |
| Cabinet Dimensions | 500 x 500 x 82 |
| Cabinet Surface Area | 0.25 m |
| Weight per Cabinet | 7.6 nit |
| Weight per Square Meter | 30.4 kg/m |
| Physical Pixel Density | 147,456 pixels/m |
| Flatness of Cabinet | +/-0.3 |
| Cabinet Material | Die-casting Magnesium |
| Service access | Front or Rear |
| Maximum brightness | 5,500 nit |
| Color Temperature | 3,200-9,300 |
| Visual Viewing Angle | 160 x 160 |
| Brightness Uniformity | 0.97 |
| Color Uniformity | +/-0.003 Cx, Cy |
| Contrast Ratio | 10,000: 1 |
| Processing Depth | 15 bit |
| Power Consumption | 180 W/Cabinet |
| Heat Dissipation | TBD |
| Power Supply | 100 to 240 |
| Frame Rate | 50 / 60 Hz |
| Refresh Rate | 3,840 Hz |
| LED Lifetime | 50,000 Half brightness |
| Operating Temperature | -30 to +50 |
| Operating Humidity | 10-99% RH |
| IP Rating Front / Rear | IP65 / IP65 |
| Certification | CE, FCC, ETL |
| Environment | RoHS |
| Controller | CVCA |
Why Buy the LG GSCF026-GP from Trianze Tech?
- Genuine LG LED signage from Trianze Tech, an authorized LG partner, sourced through authorized channels with local UAE support
- Pre-sales help sizing and planning the wall around the GSCF026-GP
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation and content advice for retail, corporate and outdoor projects
What's Included and Support
Frequently asked
LG GSCF026-GP: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The LG GSCF026-GP is an LG outdoor LED display cabinet from the Outdoor LED Series, with a 2.6 mm pixel pitch and 5,500 nit nit brightness. Trianze Tech supplies it in the UAE with project advice.
For the LG GSCF026-GP, LG lists the following. Pixel Pitch: 2.6 mm; Maximum brightness: 5,500 nit; Color Temperature: 3,200-9,300; Visual Viewing Angle: 160 x 160; Brightness Uniformity: 0.97.
For the LG GSCF026-GP, LG lists the following. Module Resolution: 96 x 96; Module Dimensions: 250 x 250; Weight per Module: 0.81 kg; No. of Modules per Cabinet: 2 x 2; Cabinet Resolution: 192 x 192.
For the LG GSCF026-GP, LG lists the following. Power Consumption: 180 W/Cabinet; Heat Dissipation: TBD; Power Supply: 100 to 240; Frame Rate: 50 / 60 Hz.
For the LG GSCF026-GP, LG lists the following. Service access: Front or Rear; LED Lifetime: 50,000 Half brightness; Operating Temperature: -30 to +50; Operating Humidity: 10-99% RH; IP Rating Front / Rear: IP65 / IP65.
Trianze Tech stocks the LG GSCF026-GP in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
