Brand
:
Samsung
Model
:
QM65F (LH65QMFPLGC/XD / LH65QMFEBLG/GO)
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Key Features
The Samsung QM65F represents a significant engineering achievement in large-format digital infrastructure for the Middle Eastern enterprise market. By integrating advanced multi-source processing, Samsung allows UAE system integrators to replace complex multi-monitor setups with a single 65-inch 4K canvas. This display is specifically hardened for the GCC climate, utilizing an industrial-grade cooling architecture and non-glare panel technology that ensures critical informational messaging remains vibrant and clear. Whether deployed in a DIFC boardroom for high-stakes presentations or an Abu Dhabi command center for 24/7 situational monitoring, the QM65F provides the ultimate balance of visual prestige and industrial resilience.
Technical Specifications & Performance Detail
- Global Inventory and Asset Identifiers: Classified officially under the professional multipurpose model code QM65F, featuring the primary Middle East manufacturer part number code LH65QMFPLGC/ZN (often designated as the regional MG variant) alongside international engineering validation stock codes LH65QMFPLGC/EN and LH65QMFPLGC/GO. Trianze Tech maintains local stock to ensure rapid fulfillment for regional GCC and CIS project tenders requiring official regional warranty compliance.
- Visual Panel and Backlight Architecture: Features a premium 65-inch Edge-Lit LED professional-grade panel achieving a native 4K UHD resolution of 3840 x 2160 pixels. The display utilizes a 60Hz refresh rate to ensure fluid motion for both high-end promotional video and detailed real-time data visualization.
- Luminance and Anti-Glare Properties: Delivers a continuous peak brightness output of 500 nits (cd/m²), engineered specifically to remain visible in brightly lit UAE corporate atriums. The panel is outfitted with an advanced anti-reflective coating that diffuses harsh light reflections from floor-to-ceiling glass facades without sacrificing color depth or contrast.
- Contrast Performance and Color Depth: Engineered around a native 4000:1 static contrast ratio utilizing a 10-bit internal color processing engine. This architecture represents 1.07 billion unique color coordinates across a professional spectrum, providing the chromatic accuracy required for brand-sensitive retail and corporate assets.
- Integrated Computing and Multi-Screen Logic: Equipped with an uncompressed internal processor supporting Picture-by-Picture (PBP) functionality. This allows up to four individual Full HD signals to be viewed concurrently on one screen, eliminating the need for external video processors in complex UAE monitoring environments.
- Physical Enclosure and Mounting Mechanics: Features a sophisticated symmetrical bezel frame designed for seamless integration into high-end fit-outs. This chassis is complemented by industrial-standard VESA 400 x 400 millimeter physical mounting points, specifically designed to distribute display weight evenly for secure structural installation on UAE wall systems.
- Signal and Management Interface Ports: Configured with four physical HDMI 2.0 (HDCP 2.2) input ports, two DisplayPort 1.2 interface terminals, and dedicated USB media slots. Control and automation are managed via an industrial RJ-45 Ethernet network connection jack and dedicated RS-232C control input/output loops for integration with centralized boardroom systems.
Enterprise Software & UC Platform Ecosystem Compatibility
- Unified Communications Platform Readiness: Fully validated for use with professional video conferencing endpoints such as Microsoft Teams Rooms (MTR), Zoom Rooms, and Cisco Webex, providing a high-detail visual endpoint for hybrid meetings.
- Collaborative Endpoint Support: Native structural compatibility with Samsung MagicINFO for centralized content scheduling and hardware health monitoring across UAE regional offices.
- Automation Control Integration: Direct structural compatibility and driver availability for Crestron Connected, Extron IP Link, and AMX automated boardroom control architectures.
Regional Regulatory & Electrical Compliance
- UAE Market Standardization: Fully certified with the UAE Ministry of Industry and Advanced Technology (MoIAT) regulatory safety standards and the Emirates Authority for Standardization and Metrology (ESMA).
- Local Power Optimization: Outfitted with a native UK-standard 3-pin Type G electrical power cord specifically configured for the UAE national grid (220V - 240V at 50/60Hz).
- International Facilities Sign-Off: Holds official international CB Scheme, CE, and RoHS safety markers, ensuring immediate corporate facility acceptance for high-tier Dubai and Abu Dhabi real estate.
Logistics, Packaging & Spatial Handling Parameters
- Net Unpacked Hardware Dimensions: Measures a structural width of 1467.4 millimeters, a total frame height of 848.0 millimeters, and an absolute physical depth thickness of 56.5 millimeters.
- Gross Protective Shipping Dimensions: Encased in heavy-duty commercial freight boxes tracking an outer shipping layout width of 1605 millimeters, an overall box height of 985 millimeters, and a package depth thickness of 200 millimeters.
- Net Hardware Mass Displacement: Tracks an unmounted, standalone display unit weight of exactly 24.8 kilograms, ensuring a manageable load for standard UAE interior fit-out wall systems.
- Gross Freight Transit Weight Infrastructure: Computes an aggregated total package mass scale of 32.0 kilograms per single crated cargo asset box to ensure seamless freight dispatching through industrial regional logistics routes across the GCC.
Key Features
The Samsung QM65F represents a significant engineering achievement in large-format digital infrastructure for the Middle Eastern enterprise market. By integrating advanced multi-source processing, Samsung allows UAE system integrators to replace complex multi-monitor setups with a single 65-inch 4K canvas. This display is specifically hardened for the GCC climate, utilizing an industrial-grade cooling architecture and non-glare panel technology that ensures critical informational messaging remains vibrant and clear. Whether deployed in a DIFC boardroom for high-stakes presentations or an Abu Dhabi command center for 24/7 situational monitoring, the QM65F provides the ultimate balance of visual prestige and industrial resilience.
Technical Specifications & Performance Detail
- Global Inventory and Asset Identifiers: Classified officially under the professional multipurpose model code QM65F, featuring the primary Middle East manufacturer part number code LH65QMFPLGC/ZN (often designated as the regional MG variant) alongside international engineering validation stock codes LH65QMFPLGC/EN and LH65QMFPLGC/GO. Trianze Tech maintains local stock to ensure rapid fulfillment for regional GCC and CIS project tenders requiring official regional warranty compliance.
- Visual Panel and Backlight Architecture: Features a premium 65-inch Edge-Lit LED professional-grade panel achieving a native 4K UHD resolution of 3840 x 2160 pixels. The display utilizes a 60Hz refresh rate to ensure fluid motion for both high-end promotional video and detailed real-time data visualization.
- Luminance and Anti-Glare Properties: Delivers a continuous peak brightness output of 500 nits (cd/m²), engineered specifically to remain visible in brightly lit UAE corporate atriums. The panel is outfitted with an advanced anti-reflective coating that diffuses harsh light reflections from floor-to-ceiling glass facades without sacrificing color depth or contrast.
- Contrast Performance and Color Depth: Engineered around a native 4000:1 static contrast ratio utilizing a 10-bit internal color processing engine. This architecture represents 1.07 billion unique color coordinates across a professional spectrum, providing the chromatic accuracy required for brand-sensitive retail and corporate assets.
- Integrated Computing and Multi-Screen Logic: Equipped with an uncompressed internal processor supporting Picture-by-Picture (PBP) functionality. This allows up to four individual Full HD signals to be viewed concurrently on one screen, eliminating the need for external video processors in complex UAE monitoring environments.
- Physical Enclosure and Mounting Mechanics: Features a sophisticated symmetrical bezel frame designed for seamless integration into high-end fit-outs. This chassis is complemented by industrial-standard VESA 400 x 400 millimeter physical mounting points, specifically designed to distribute display weight evenly for secure structural installation on UAE wall systems.
- Signal and Management Interface Ports: Configured with four physical HDMI 2.0 (HDCP 2.2) input ports, two DisplayPort 1.2 interface terminals, and dedicated USB media slots. Control and automation are managed via an industrial RJ-45 Ethernet network connection jack and dedicated RS-232C control input/output loops for integration with centralized boardroom systems.
Enterprise Software & UC Platform Ecosystem Compatibility
- Unified Communications Platform Readiness: Fully validated for use with professional video conferencing endpoints such as Microsoft Teams Rooms (MTR), Zoom Rooms, and Cisco Webex, providing a high-detail visual endpoint for hybrid meetings.
- Collaborative Endpoint Support: Native structural compatibility with Samsung MagicINFO for centralized content scheduling and hardware health monitoring across UAE regional offices.
- Automation Control Integration: Direct structural compatibility and driver availability for Crestron Connected, Extron IP Link, and AMX automated boardroom control architectures.
Regional Regulatory & Electrical Compliance
- UAE Market Standardization: Fully certified with the UAE Ministry of Industry and Advanced Technology (MoIAT) regulatory safety standards and the Emirates Authority for Standardization and Metrology (ESMA).
- Local Power Optimization: Outfitted with a native UK-standard 3-pin Type G electrical power cord specifically configured for the UAE national grid (220V - 240V at 50/60Hz).
- International Facilities Sign-Off: Holds official international CB Scheme, CE, and RoHS safety markers, ensuring immediate corporate facility acceptance for high-tier Dubai and Abu Dhabi real estate.
Logistics, Packaging & Spatial Handling Parameters
- Net Unpacked Hardware Dimensions: Measures a structural width of 1467.4 millimeters, a total frame height of 848.0 millimeters, and an absolute physical depth thickness of 56.5 millimeters.
- Gross Protective Shipping Dimensions: Encased in heavy-duty commercial freight boxes tracking an outer shipping layout width of 1605 millimeters, an overall box height of 985 millimeters, and a package depth thickness of 200 millimeters.
- Net Hardware Mass Displacement: Tracks an unmounted, standalone display unit weight of exactly 24.8 kilograms, ensuring a manageable load for standard UAE interior fit-out wall systems.
- Gross Freight Transit Weight Infrastructure: Computes an aggregated total package mass scale of 32.0 kilograms per single crated cargo asset box to ensure seamless freight dispatching through industrial regional logistics routes across the GCC.
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Book a call
You can purchase the Samsung QM65F directly from the official Trianze Tech B2B e-commerce platform at trianzetech.ae. For enterprise corporate pricing models, regional project quotes, bulk commercial procurement orders, or immediate installation support across Dubai, Abu Dhabi, and the wider GCC region, please reach out directly to our dedicated sales and distribution team via email at avsupport@trianzetech.ae, connect through our official website portal, or call our B2B account support line directly at +971 58 161 3661.
Procuring professional 65-inch edge-lit commercial screens requires strict transport protocols due to their precise internal component alignment. Moving these panels requires specific measures to prevent panel flexing or glass fractures during transit. By centralizing operations at our Dubai office, TrianzeTech manages localized quality checks, applies reinforced dual-pallet industrial crating, and handles targeted customs documentation. This reduces transit times and eliminates delivery complications for projects expanding into Cairo, Almaty, and the wider CIS territory.
Standard displays require a dedicated external multi-window processor or matrix switch to split the screen layout, adding complexity, extra video cables, and multiple potential points of failure. The Samsung QM65F features an integrated Quad-FHD PBP processing matrix. It accepts up to four entirely separate video source connections directly into its hardware terminals, neatly tiling them into equal screen quadrants. Each quadrant displays uncompressed Full HD 1080p resolution, providing a clean, seamless multi-source workspace on a single display.
Many older or lower-tier 4K commercial screens only support 4K input over HDMI 1.4 or legacy interfaces, which caps the visual refresh rate at a choppy 30Hz. For applications like viewing panning security camera feeds, reading scrolling stock tickers, or interacting with rapid telemetry changes, a 30Hz limit causes fatiguing motion blur and jagged transitions. The QM65F features Dual DisplayPort 1.2 interfaces that natively support 4K at a smooth 60Hz refresh rate, ensuring fast-moving text and high-speed data animations remain sharp and easy on the eyes.
Mounting external media players behind wall-installed monitors often leads to messy cabling, extra wall-space requirements, and higher field maintenance effort. The QM65F solves this issue with its integrated Set-Back Box (SBB) slide-in bay. An SBB media module can slide directly into the display chassis, connecting internally to power and video lines. This creates a clean, self-contained, enterprise-grade all-in-one terminal that saves space and simplifies network management.
