LG MAGNIT Gen 2 LMPB007BANA 0.78mm Micro LED Display Cabinet
Model
:
LMPB007BANA
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 or Chat on WhatsApp
LG MAGNIT Gen 2 LMPB007BANA 0.78mm Micro LED Display Cabinet
An ultra-high resolution Micro LED display cabinet built for close-viewing premium spaces such as boardrooms, studios, control rooms, and broadcast environments across Dubai, Abu Dhabi, and the UAE.
Key Features:
- 0.78mm pixel pitch for ultra-high resolution close-viewing visuals
- 1,000 nit peak brightness, 500 nit typical, calibrated for professionally lit environments
- Up to 20,000:1 contrast ratio with full black coating and advanced surface treatment
- 96/100/120Hz frame rates for smooth broadcast and real-time visualization content
- Cable-less signal transmission design, requiring only connections to the system controller and power source
Technical Specifications:
| Technical Parameter | Specification |
| Brand & Model | LG LMPB007BANA |
| LED Type | Micro LED |
| Pixel Pitch | 0.78mm |
| Module Resolution | 384 x 144 |
| Cabinet Resolution | 768 x 432 |
| Cabinet Dimensions | 600 x 337.5 x 39.8mm |
| Weight per Cabinet | 5.4 kg |
| Max Brightness (Calibrated) | Up to 500 nits |
| Contrast Ratio | 20,000:1 |
| Frame Rate | 96 / 100 / 120 Hz |
| Viewing Angle | 160 x 160 Degrees |
| Processing Depth | 20-bit, HDR10 and HDR10 Pro |
| Service Access | Front |
| IP Rating | IP50 Front, IP20 Rear |
| Lifetime (Half Brightness) | Up to 100,000 Hours |
| Signal Transmission | SFP+ Compatible, Up to 10km from Controller |
| Warranty | 3 Year Limited |
Why Buy the LG LMPB007BANA from Trianze Tech?
- Genuine LG stock with full manufacturer warranty
- Fast delivery and installation across Dubai, Abu Dhabi, and the wider GCC
- Dedicated AV integration support for premium video wall projects
- Competitive pricing with flexible corporate and government quotes
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
It converts pixel defects that would normally appear as a full line error into a single isolated dot, minimizing visual disruption.
No, it uses a cable-less signal transmission design, requiring only connections to the system controller and power source.
With SFP+ compatibility, the controller can be placed up to 10 kilometers away from the display.
Yes, it supports HDR10 and LG's own HDR10 Pro processing for enhanced dynamic tone mapping.
It supports front service access, along with z-axis depth adjustment from both the front and rear for greater installation flexibility.
