Shure MXN-AMP: Microflex PoE+ Powered Networked Amplifier with 4 Dante Inputs and Outputs, 8 Ohm and 70V Loudspeaker Outputs
Model
:
MXN-AMP
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure MXN-AMP Microflex PoE+ Networked Conferencing Amplifier
The Shure MXN-AMP is a PoE+ powered multichannel amplifier for Microflex conferencing loudspeakers. It drives up to four MXN or MXP loudspeakers in 8 ohm mode or up to eight MXP-5 or MXP-6 in 70V mode, with four Dante inputs and outputs and onboard Shure DSP. It is plenum rated and mounts in a rack, on a wall or in a ceiling for meeting rooms across Dubai, Abu Dhabi and the UAE and GCC.
Key Features:
- Powers up to 4 MXN or MXP loudspeakers in 8 ohm mode or up to 8 MXP-5/MXP-6 in 70V mode
- 14.5 W combined output power from PoE+
- Four Dante inputs and four Dante outputs
- Unbalanced stereo analog input and logic input for preset switching
- Onboard Shure DSP: EQ, delay, limiter, signal and tone generator
- Presets for all MXP-series loudspeakers
- 802.1X, secure boot and AES encryption for control and audio
- UL 2043 plenum rated
Technical Specifications:
| Spec | Value |
|---|---|
| Model | MXN-AMP |
| Power | PoE+ |
| Output Power | 14.5 W combined |
| Speaker Outputs | 4 x LoZ (8 ohm) and 70V output |
| Network Audio | 4 Dante inputs, 4 Dante outputs |
| Analog Input | Unbalanced stereo |
| Logic Input | Switches between presets 1 and 2 |
| DSP | EQ, delay, limiter, signal and tone generator |
| Security | 802.1X, secure boot and storage, AES encryption |
| Rating | UL 2043 plenum |
| Mounting | Rack (CRT-1 tray), wall or ceiling |
Why Buy the Shure MXN-AMP from Trianze Tech?
- Genuine Shure product supplied through authorized channels with local UAE support
- Loudspeaker count, wiring mode and preset planning for your MXP installation
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance from our AV team on system design and compatible Shure accessories
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The MXN-AMP can power up to four MXN or MXP loudspeakers in 8 ohm mode, or up to eight MXP-5 or MXP-6 loudspeakers in 70V mode.
The MXN-AMP is rated at 14.5 watts of combined output power and is powered entirely by PoE+.
The MXN-AMP has four Dante inputs and four Dante outputs, an unbalanced stereo analog audio input and a logic input that switches between presets 1 and 2.
Yes. Onboard Shure DSP provides EQ, delay, limiter and a signal and tone generator, with presets for all MXP-series loudspeakers and custom presets in the control software.
Yes. The MXN-AMP is UL 2043 plenum rated and can be wall or ceiling mounted, or rack mounted with the optional CRT-1 rack tray. Shure recommends a safety tether for overhead installs.
