Q-SYS NC-Pro15x White: PTZ Network Camera Canon Optics 4K UHD, White
Model
:
NC-Pro15x White
Buying guides for this product
- Best Video Bar by Room Size
- All-in-One Video Conferencing Display vs TV and Video Bar
- Microsoft Teams Rooms on Windows vs Android
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Q-SYS NC-Pro15x White at a Glance
- Brand
- Q-SYS
- Model
- NC-Pro15x White
- Category
- Video Conferencing Cameras
- Solution
- Video Conferencing
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Q-SYS NC-Pro15x White Overview
The NC-Pro15x expands the Q-SYS camera portfolio to bring broadcast-quality video to high-impact spaces that require elevated production-grade elements. Built by Canon, the NC-Pro15x is a network PTZ camera that delivers smooth and responsive pan, tilt, and zoom performance to enhance the VisionSuite Presenter Spotlight experience. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Built by Canon, the NC-Pro15x is a network PTZ camera that delivers smooth and responsive pan, tilt, and zoom performance to enhance the VisionSuite Presenter Spotlight experience.
- Description: Network camera with motorized PTZ, 15x optical zoom (20x digital) and 73 degrees horizontal FoV
- Image sensor: 1.0" single-plate CMOS
- Lens characteristics (wide to tele): 15x optical zoom f=8.3 mm to 124.5 mm, F2.8 to F4.5
- Sensor scanning mode: Progressive
- Horizontal rotation range: +/-170 degrees
Technical Specifications:
| Spec | Value |
|---|---|
| Model | NC-Pro15x White |
| Brand | Q-SYS |
| Description | Network camera with motorized PTZ, 15x optical zoom (20x digital) and 73 degrees horizontal FoV |
| Image sensor | 1.0" single-plate CMOS |
| Lens characteristics (wide to tele) | 15x optical zoom f=8.3 mm to 124.5 mm, F2.8 to F4.5 |
| Sensor scanning mode | Progressive |
| Horizontal rotation range | +/-170 degrees |
| Vertical rotation range | -30 degrees to +90 degrees |
| Ceiling mountable | Yes (flush-mount accessory included) |
| Audio inputs (XLR/3.5 mm) | Inactive |
| Minimum illumination | 3840 x 2160: Approx. 1.5 lux (shutter speed 1/30 sec., 29.97 Hz, gain 33.0 dB) 1920 x 1080: Approx. 3 lux (shutter speed 1/60 sec., 59.94 Hz, gain 33.0 dB) |
| Shutter | 1/3 s to 1/2000 s |
| White balance | Auto, Set A, Set B, daylight, tungsten lamp, manual, specified color temperature |
| IP stream resolutions (preview window) | H.264 @ 360p |
| Supported Video Formats: HDMI 2.0 output | 3840 x 2160: 29.97P, 25.00P, 23.98P fps 1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P fps 1280 x 720: 59.94P, 50.00P fps x Same video format required for SDI and HDMI x When 3840 x 2160 is selected for HDMI |
| Supported Video Formats: SDI-3G output | 1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P fps 1280 x 720: 59.94P, 50.00P fps x Same video format required for SDI and HDMI |
| Supported Video Formats: NDI | HX2 + Q-SYS Bridging | 1080p @ 29.97, 25 |
| Supported Video Formats: NDI | HX2 without Q-SYS Bridging | 4K @ 29.97, 25, 15 fps 1080p @ 59.94, 50, 29.97, 25, 15 fps 720p @ 59.94, 50, 29.97, 25, 15 fps 360p @ 59.94, 50, 29.97, 25, 15 fps x To use 4K output, users will need to deploy the NC-Pro15x in "NDI Only" mode. |
| Supported Video Formats: Power over Ethernet (PoE) | PoE+ (Type 2) |
| Supported Video Formats: Size | 7.87 x 10.59 x 8.19 in (200 x 269 x 208 mm) |
| Supported Video Formats: Net weight | 9.04 lbs (4.1 kg) |
| Supported Video Formats: Accessories (sold separately) | NC-Pro15x-WM wall mount (available in black or white) |
| Supported Video Formats: Battery chemistry (embedded, non-accessible) | Lithium Carbon Monofluoride |
Why Buy the Q-SYS NC-Pro15x White from Trianze Tech?
- Genuine Q-SYS product supplied by Trianze Tech with local UAE support
- Pre-sales help designing the Q-SYS system around the NC-Pro15x White
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Q-SYS NC-Pro15x White: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The NC-Pro15x expands the Q-SYS camera portfolio to bring broadcast-quality video to high-impact spaces that require elevated production-grade elements. Built by Canon, the NC-Pro15x is a network PTZ camera that delivers smooth and responsive pan, tilt, and zoom performance to enhance the VisionSuite Presenter Spotlight experience.
For the Q-SYS NC-Pro15x White, Q-SYS lists the following. Audio inputs (XLR/3.5 mm): Inactive; White balance: Auto, Set A, Set B, daylight, tungsten lamp, manual, specified color temperature; Supported Video Formats: HDMI 2.0 output: 3840 x 2160: 29.97P, 25.00P, 23.98P fps 1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P fps 1280 x 720: 59.94P; Supported Video Formats: SDI-3G output: 1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P fps 1280 x 720: 59.94P, 50.00P fps x Same video format required; Supported Video Formats: NDI | HX2 + Q-SYS Bridging: 1080p @ 29.97, 25; Supported Video Formats: NDI | HX2 without Q-SYS Bridging: 4K @ 29.97, 25, 15 fps 1080p @ 59.94, 50, 29.97, 25, 15 fps 720p @ 59.94, 50, 29.97, 25, 15 fps 360p @ 59.94.
For the Q-SYS NC-Pro15x White, Q-SYS lists the following. Image sensor: 1.0" single-plate CMOS; Lens characteristics (wide to tele): 15x optical zoom f=8.3 mm to 124.5 mm, F2.8 to F4.5; Sensor scanning mode: Progressive; IP stream resolutions (preview window): H.264 @ 360p; Supported Video Formats: Accessories (sold separately): NC-Pro15x-WM wall mount (available in black or white).
For the Q-SYS NC-Pro15x White, Q-SYS lists the following. Supported Video Formats: Power over Ethernet (PoE): PoE+ (Type 2).
For the Q-SYS NC-Pro15x White, Q-SYS lists the following. Supported Video Formats: Size: 7.87 x 10.59 x 8.19 in (200 x 269 x 208 mm); Supported Video Formats: Net weight: 9.04 lbs (4.1 kg).
Trianze Tech stocks the Q-SYS NC-Pro15x White in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
