Epson EB-L630SU: 6,000 Lumens WUXGA 3LCD Laser Projector for Meeting Rooms and Classrooms
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Epson EB-L630SU at a Glance
- Brand
- Epson
- Model
- EB-L630SU
- Part Number
- V11HA29040DA
- Category
- Projectors
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Epson EB-L630SU Overview
The Epson EB-L630SU is an Epson business and education projector with 6,000 lumens of colour brightness, WUXGA resolution and a laser light source. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Resolution: WUXGA
- Colour Light Output, Lumens: 6000 Lumens
- Colour Light Output, Luman (economy) in accodance with: 4200 Lumens
- Colour Light Output Testing Standard: In accordance with ISO 21118:2012
- Contrast Ratio, Ratio:1: 5000000
- Contrast Ratio, Absolute black: Absolute black
- Light Source (Visual product): Laser
Technical Specifications:
| Spec | Value |
|---|---|
| Model | EB-L630SU |
| Epson part number | V11HA29040DA |
| Brand | Epson |
| Projector Colour | White |
| Loudspeaker | 10 W |
| Noise Level -Normal | 38 dB (A) |
| Noise Level -Economy | 27 dB (A) |
| Options | Connection and control box, Document camera, HDBaseT Transmitter, Wireless LAN unit, External Speaker, MB22 ceiling mount |
| Positioning | Ceiling Mounted, Desktop |
| Power consumption -(Normal On-Mode) | 287 W |
| Power consumption- (Eco On-Mode) | 164 W |
| Power consumption, (Energy saving standby) | 0.3 W |
| Product Dimensions | 440 x 334 x 136 mm (Width x Depth x Height) |
| Product Range | E9 |
| Room Type / Application | Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Signage / Retail, Visitor Attraction |
| Single Unit | ZN |
| Supply Voltage | 100 V to 240 V, 50 Hz to 60 Hz |
| Supported Humidity, Operation (from) | 20 % |
| Supported Humidity, Operation (to) | 80 % |
| Supported Humidity, Storage (from) | 10 % |
| Supported Humidity, Storage (to) | 90 % |
| Supported Temperature, Operation (to) | 45 |
| Supported Temperature, Storage (from) | -10 C |
| Supported Temperature, Storage (to) | 60 C |
| LCD Panel (Type) | 0.67 inches with |
| LCD Panel | C2 Fine |
| Projection System | 3LCD Technology, RGB liquid crystal shutter |
| Resolution | WUXGA |
| Epson iProjection App | Ad-Hoc / Infrastructure |
| Network Protocol | IPv6, ESC/VP.net, PJLink, SNMP, HTTPS |
| Network Protocol (Projector) | IPv6, ESC/VP.net, PJLink, SNMP, HTTPS |
| Warranty (Months) | 36 Months Carry-in |
| 2D Colour Modes | Dynamic, Cinema, Presentation, sRGB, DICOM SIM |
| Projector control | AMX Device Discovery, Control4 Simple Device Discovery Protocol, Extron XTP, Extron IP Link, Crestron Integrated Partner |
| Security (Visual product) | Kensington lock, Wireless LAN unit lock, Control panel lock, Security cable hole, Wireless LAN security, Password protection |
| Video Colour Modes | Dynamic, Cinema, sRGB, Presentation, DICOM SIM, Multi Projection |
| Colour Light Output, Lumens | 6000 Lumens |
| Colour Light Output, Luman (economy) in accodance with | 4200 Lumens |
| Colour Light Output Testing Standard | In accordance with ISO 21118:2012 |
| Colour Reproduction (Projector) | Upto 1.07 billion colours |
| Colour Video Processing | 10 Bits Color |
| Contrast Ratio, Ratio:1 | 5000000 |
| Contrast Ratio, Absolute black | Absolute black |
| High Definition | Full HD |
| Keystone Correction Type (Horizontal) | manual |
| Keystone Correction Angle (Horizontal) | 30 |
| Keystone Correction Type (Vertical) | manual |
| Keystone Correction Angle (Vertical) | 30 |
| Laser Lightsource -Durability High | 20000 hr |
| Laser Lightsource -Durability Eco | 30000 hr |
| Light Source (Visual product) | Laser |
| Pixel Numbers | 2304000 |
| White Light Output, Lumens | 4200 Lumens |
| White Light Output, Lumens (economy) in accodance with | 4200 Lumens |
| White Light Output Testing Standard | In accordance with ISO 21118:2020 |
| Lens | Optical |
| Lens Shift | manual |
| Lens Shift (Vertical +/-) | 50 |
| Lens Shift (Horizontal +/-) | 20 |
| Projection Distance Wide from | 0.9 m |
| Projection Distance Wide to | 3.5 |
| Projection Lens F Number from | 1.7 |
| Projection Lens Focal Length (From) | 11.76 |
Why Buy the Epson EB-L630SU from Trianze Tech?
- Genuine Epson projector from Trianze Tech, sourced through authorized channels with local UAE support
- Pre-sales help matching the EB-L630SU to your room size, screen and seating distance
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Projector screen and ceiling mount advice from our installation team
What's Included and Support
Frequently asked
Epson EB-L630SU: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The Epson EB-L630SU is an Epson business and education projector with 6,000 lumens of colour brightness, WUXGA resolution and a laser light source. Trianze Tech supplies it in the UAE with project advice.
For the Epson EB-L630SU, Epson lists the following. Resolution: WUXGA; Colour Light Output, Lumens: 6000 Lumens; Colour Light Output, Luman (economy) in accodance with: 4200 Lumens; Colour Light Output Testing Standard: In accordance with ISO 21118:2012; Contrast Ratio, Ratio:1: 5000000; Contrast Ratio, Absolute black: Absolute black.
For the Epson EB-L630SU, Epson lists the following. Throw Ratio from: 0.8; Throw Ratio to: 1.07; Screen Size from: 50 in; Screen Size to: 200 in; Lens: Optical.
For the Epson EB-L630SU, Epson lists the following. Network Protocol: IPv6, ESC/VP.net, PJLink, SNMP, HTTPS; Network Protocol (Projector): IPv6, ESC/VP.net, PJLink, SNMP, HTTPS.
For the Epson EB-L630SU, Epson lists the following. Product Dimensions: 440 x 334 x 136 mm (Width x Depth x Height); Power consumption -(Normal On-Mode): 287 W; Power consumption- (Eco On-Mode): 164 W; Power consumption, (Energy saving standby): 0.3 W; Supply Voltage: 100 V to 240 V, 50 Hz to 60 Hz.
Trianze Tech stocks the Epson EB-L630SU in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
