d&b audiotechnik 27S-SUB: 15 Inch and 12 Inch Compact Cardioid Passive Installation Subwoofer
Model
:
27S-SUB
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
d&b audiotechnik 27S-SUB Compact Cardioid Passive Installation Subwoofer
The d&b audiotechnik 27S-SUB is a compact high performance cardioid subwoofer for xS-Series and xA-Series loudspeakers, powered from a single amplifier channel. It combines a front facing 15 inch driver in a bass reflex design with a rear facing 12 inch driver in a two chamber bandpass, giving cardioid low frequency control from 40 to 140 Hz. Trianze Tech supplies the 27S-SUB for installed sound projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Integrated cardioid setup from one amplifier channel
- Front 15 inch neodymium driver in bass reflex design
- Rear 12 inch neodymium driver in two chamber bandpass
- Frequency response from 40 Hz to 140 Hz
- Marine plywood cabinet, ball impact resistant to DIN 18032-3
- 2 x NL4 connectors plus a screw terminal block
Technical Specifications:
| Spec | Value |
|---|---|
| Model | 27S-SUB |
| Type | Installation cardioid subwoofer, passive |
| Components | 15 inch front driver, 12 inch rear driver, neodymium |
| Dispersion | Cardioid |
| Frequency Response (-5 dB) | 40 to 140 Hz standard, 40 to 100 Hz CUT mode |
| Max SPL | 128 dB (10D), 131 dB (D20/5D/30D/D40/D80/40D) |
| Nominal Impedance | 6 ohms |
| Power Handling (RMS/peak) | 500/2000 W |
| Cabinets per Amplifier Channel | 2 |
| Connections | 2 x NL4, screw terminal block |
| Dimensions (H x W x D) | 490 x 580 x 700 mm |
| Weight | 41 kg (90 lb) |
Why Buy the d&b audiotechnik 27S-SUB from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the 27S-SUB with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik 27S-SUB has a front facing 15 inch driver and a rear facing 12 inch driver in an integrated cardioid setup, which cancels low frequency energy behind the cabinet.
No. The d&b audiotechnik 27S-SUB achieves its cardioid pattern from a single amplifier channel, and two cabinets can share one channel.
The d&b audiotechnik 27S-SUB covers 40 Hz to 140 Hz (-5 dB) in standard mode and 40 Hz to 100 Hz in CUT mode.
The d&b audiotechnik 27S-SUB reaches 131 dB maximum SPL with D20, 5D, 30D, D40, D80 or 40D amplifiers, and 128 dB with the 10D.
The d&b audiotechnik 27S-SUB measures 490 x 580 x 700 mm (H x W x D) and weighs 41 kg (90 lb).
