d&b audiotechnik 21S-SUB: 21 Inch High Performance Passive Installation Subwoofer
Model
:
21S-SUB
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
d&b audiotechnik 21S-SUB 21 Inch High Performance Passive Installation Subwoofer
The d&b audiotechnik 21S-SUB is a high performance subwoofer for xS-Series and xA-Series loudspeakers in permanent installations. A long excursion 21 inch driver and a specially shaped reflex port deliver high SPL from a small footprint, and INFRA mode extends a system down to 33 Hz. Trianze Tech supplies the 21S-SUB for installed sound projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Single long excursion 21 inch neodymium driver
- Specially shaped reflex port for high SPL from a small footprint
- INFRA mode extends system response down to 33 Hz
- Ground stacked or flown in either orientation
- Fly individually or in a cluster of two cabinets
- M10 threaded inserts on top, bottom and rear panels
Technical Specifications:
| Spec | Value |
|---|---|
| Model | 21S-SUB |
| Type | Installation high performance subwoofer, passive |
| Driver | 21 inch neodymium, long excursion |
| Frequency Response (-5 dB) | 35 to 105 Hz standard, 33 to 85 Hz INFRA mode |
| Max SPL | 134 dB (D20/30D), 135 dB (D80) |
| Nominal Impedance | 4 ohms |
| Power Handling (RMS/peak) | 650/2600 W |
| Cabinets per Amplifier Channel | 1 |
| Dimensions (H x W x D) | 43.3 x 22.8 x 20.7 inches (approx.) |
| Weight | 54 kg (119 lb) |
Why Buy the d&b audiotechnik 21S-SUB from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the 21S-SUB with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik 21S-SUB covers 35 Hz to 105 Hz (-5 dB) in standard mode, and 33 Hz to 85 Hz in INFRA mode.
INFRA mode lets the d&b audiotechnik 21S-SUB complement other d&b subwoofers by extending the system frequency response down to 33 Hz.
The d&b audiotechnik 21S-SUB reaches 134 dB maximum SPL with a D20 or 30D amplifier, and 135 dB with a D80.
The d&b audiotechnik 21S-SUB has a 4 ohm nominal impedance, handles 650 W RMS and 2600 W peak, and runs one cabinet per amplifier channel.
Yes. The d&b audiotechnik 21S-SUB can be ground stacked or flown in either orientation, individually or in a cluster of two cabinets.
Trianze Tech supplies the d&b audiotechnik 21S-SUB in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
