d&b audiotechnik 24S-D: 2 x 12 Inch Wide Dispersion Passive Installation Loudspeaker, 110 x 45 Degree
Model
:
24S-D
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
d&b audiotechnik 24S-D 2 x 12 Inch Wide Dispersion Passive Installation Loudspeaker
The d&b audiotechnik 24S-D is the wide dispersion version of the 24S, a high performance full range 2-way passive loudspeaker with two dipolar 12 inch drivers and a 1.4 inch exit compression driver on a rotatable CD horn. Its 110 x 45 degree pattern covers wider audience areas, with 137 dB maximum SPL and response down to 55 Hz. Trianze Tech supplies the 24S-D for installed sound projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Wide 110 x 45 degree rotatable dispersion
- Two 12 inch neodymium drivers in a dipolar arrangement
- 1.4 inch exit compression driver on a CD horn
- Frequency response from 55 Hz to 18 kHz
- Marine plywood cabinet, ball impact resistant to DIN 18032-3
- M10 threaded inserts on top, bottom and side panels
Technical Specifications:
| Spec | Value |
|---|---|
| Model | 24S-D |
| Type | Installation full range 2-way loudspeaker, wide dispersion, passive |
| Components | 2 x 12 inch neodymium drivers, 1.4 inch exit compression driver |
| Dispersion (h x v) | 110 x 45 degrees, rotatable |
| Frequency Response (-5 dB) | 55 Hz to 18 kHz standard, 90 Hz to 18 kHz CUT mode |
| Max SPL | 137 dB |
| Nominal Impedance | 4 ohms |
| Power Handling (RMS/peak) | 500/2000 W |
| Cabinets per Amplifier Channel | 1 |
| Connections | 1 x NL4, 1 x screw terminal block |
| Dimensions (H x W x D) | 800 x 410 x 420 mm |
| Weight | 33 kg (73 lb) |
Why Buy the d&b audiotechnik 24S-D from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the 24S-D with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik 24S-D is the wide dispersion version of the 24S, with a 110 x 45 degree pattern instead of 75 x 45 degrees. Its maximum SPL is 137 dB versus 138 dB for the 24S.
The d&b audiotechnik 24S-D covers 55 Hz to 18 kHz (-5 dB) in standard mode and 90 Hz to 18 kHz in CUT mode.
Yes. The CD horn of the d&b audiotechnik 24S-D rotates by 90 degrees, so the cabinet can be used vertically or horizontally.
The d&b audiotechnik 24S-D reaches 137 dB with D20, 30D, D40, D80 or 40D amplifiers, at one cabinet per amplifier channel and 4 ohms nominal impedance.
The d&b audiotechnik 24S-D measures 800 x 410 x 420 mm (H x W x D) and weighs 33 kg (73 lb).
