d&b audiotechnik Bi8-SUB Installation Ultra Compact 2 x 6.5 Inch Subwoofer
The d&b audiotechnik Bi8-SUB is the installation version of the B8 ultra compact subwoofer, differing only in cabinet construction and mounting hardware. Two 6.5 inch drivers in a bass reflex cabinet just 170 mm high extend from 43 Hz to 170 Hz, and it pairs with d&b xC, xS and E-Series loudspeakers. Trianze Tech supplies the Bi8-SUB for installed sound in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Installation version of the B8-SUB
- Two 6.5 inch drivers in a bass reflex cabinet
- Low 170 mm cabinet height
- Frequency response from 43 Hz to 170 Hz
- Flown horizontally or vertically via M8 side inserts
- 2 x NL4 connectors and a screw terminal block
Technical Specifications:
| Spec | Value |
|---|---|
| Model | Bi8-SUB |
| Type | Installation ultra compact subwoofer, passive |
| Components | 2 x 6.5 inch drivers, ferrite magnet |
| Dispersion | Omnidirectional |
| Frequency Response (-5 dB) | 43 to 170 Hz standard, 43 to 125 Hz 100 Hz mode |
| Max SPL | 120 dB (10D), 122 dB (D20/30D/D40/D80/40D) |
| Nominal Impedance | 8 ohms |
| Power Handling (RMS/peak) | 200/800 W |
| Cabinets per Amplifier Channel | 2 |
| Connections | 2 x NL4 M (pins 2+/2-), screw terminal block |
| Dimensions (H x W x D) | 170 x 436 x 580 mm |
| Weight | 17 kg (37.5 lb) |
Why Buy the d&b audiotechnik Bi8-SUB from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the Bi8-SUB with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik Bi8-SUB is the installation version of the B8-SUB and differs only in cabinet construction and mounting hardware. The acoustic performance is the same.
The d&b audiotechnik Bi8-SUB is only 170 mm high, measuring 170 x 436 x 580 mm (H x W x D) and weighing 17 kg (37.5 lb).
The d&b audiotechnik Bi8-SUB covers 43 Hz to 170 Hz (-5 dB) in standard mode and 43 Hz to 125 Hz in 100 Hz mode.
The d&b audiotechnik Bi8-SUB reaches 122 dB maximum SPL with D20, 30D, D40, D80 or 40D amplifiers, and 120 dB with the 10D.
The d&b audiotechnik Bi8-SUB has two NL4 connectors (pins 2+/2-) and a two pole screw terminal block on the rear panel.
