d&b audiotechnik B8-SUB: 2 x 6.5 Inch Ultra Compact Passive Subwoofer with NLT4 F/M Connections
Model
:
B8-SUB NLT4
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
d&b audiotechnik B8-SUB Ultra Compact Subwoofer with NLT4 F/M Connections
The d&b audiotechnik B8-SUB is an ultra compact subwoofer that pairs with d&b xC, xS and E-Series loudspeakers, using two 6.5 inch drivers in a bass reflex cabinet just 170 mm high. It extends from 43 Hz to 170 Hz, can be flown horizontally or vertically, and its M20 flange accepts a d&b loudspeaker stand for tops up to 8 kg. Trianze Tech supplies the B8-SUB for compact mobile systems in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Two 6.5 inch drivers in a bass reflex cabinet
- Low 170 mm cabinet height
- Frequency response from 43 Hz to 170 Hz
- M20 flange for the d&b Z5013 stand, top load up to 8 kg
- Flown horizontally or vertically via M8 side inserts
- NLT4 F/M connectors, pin assignment 2+/2-
Technical Specifications:
| Spec | Value |
|---|---|
| Model | B8-SUB, NLT4 F/M version |
| Type | Ultra compact subwoofer, passive |
| Components | 2 x 6.5 inch drivers, ferrite magnet |
| Frequency Response (-5 dB) | 43 to 170 Hz standard, 43 to 125 Hz 100 Hz mode |
| Max SPL | 120 dB (10D), 122 dB (D20/5D/30D/D40/D80/40D) |
| Nominal Impedance | 8 ohms |
| Power Handling (RMS/peak) | 200/800 W |
| Cabinets per Amplifier Channel | 2 |
| Connections | 2 x NLT4 F/M, pins 2+/2- |
| Dimensions (H x W x D) | 170 x 436 x 580 mm |
| Weight | 18 kg (39 lb) |
Why Buy the d&b audiotechnik B8-SUB NLT4 from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the B8-SUB NLT4 with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik B8-SUB is designed to pair with d&b xC, xS and E-Series loudspeakers in small scale mobile systems.
The d&b audiotechnik B8-SUB is only 170 mm high, measuring 170 x 436 x 580 mm (H x W x D) and weighing 18 kg (39 lb).
Yes. The M20 flange on the d&b audiotechnik B8-SUB accepts the d&b Z5013 loudspeaker stand for full range cabinets up to 8 kg (17.6 lb).
The d&b audiotechnik B8-SUB covers 43 Hz to 170 Hz in standard mode and 43 Hz to 125 Hz in 100 Hz mode, with 122 dB maximum SPL.
Yes. The d&b audiotechnik B8-SUB can be flown horizontally or vertically using a dedicated flying bracket on its M8 side inserts.
Trianze Tech supplies the d&b audiotechnik B8-SUB NLT4 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
