d&b audiotechnik E12: 12 Inch Coaxial 2 Way Passive Loudspeaker, 80 x 50 Degree Horn, NLT4 F/M Connectors
Model
:
E12 NLT4 F/M
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
d&b audiotechnik E12 12 Inch Coaxial Loudspeaker with NLT4 F/M Connectors
The d&b audiotechnik E12 is a high performance 2 way multipurpose loudspeaker with an integrated 12 inch and 1.3 inch coaxial driver, for speech and music as a stand alone full range system or within larger distributed systems. Its 80 x 50 degree horn rotates through 90 degrees, and the multifaceted cabinet works upright, horizontal or as a stage monitor. This version has 2 x NLT4 F/M connectors. Trianze Tech supplies the E12 in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 12 inch neodymium driver with coaxial 1.3 inch compression driver
- 80 x 50 degree horn, rotatable to 50 x 80 degrees
- Up to 134 dB SPLmax with D12
- Upright, horizontal or stage monitor use
- Polyurethane integral hard foam cabinet
- 2 x NLT4 F/M connectors
Technical Specifications:
| Spec | Value |
|---|---|
| Model | E12 (NLT4 F/M) |
| Type | 2 way coaxial passive loudspeaker |
| Frequency Response | 50 Hz to 18 kHz (standard), 100 Hz to 18 kHz (CUT mode), -5 dB |
| Max SPL | 131 dB with D6, 134 dB with D12 |
| Input Level (100 dB SPL/1 m) | -17 dBu |
| Nominal Impedance | 8 ohms |
| Power Handling | 300 W RMS / 1600 W peak (10 ms) |
| Dispersion | 80 x 50 degrees, rotatable |
| Components | 12 inch neodymium driver, coaxial 1.3 inch compression driver with 3 inch coil, passive crossover |
| Connections | 2 x NLT4 F/M |
| Weight | 16 kg (35 lb) |
Why Buy the d&b audiotechnik E12 NLT4 F/M from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the E12 NLT4 F/M with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
This d&b audiotechnik E12 version is fitted with 2 x NLT4 F/M connectors.
The d&b audiotechnik E12 handles 300 W RMS and 1600 W peak (10 ms) at a nominal impedance of 8 ohms.
Yes. The horn of the d&b audiotechnik E12 rotates through 90 degrees, changing the 80 x 50 degree pattern to 50 x 80 degrees.
d&b audiotechnik names the E15X and B4 subwoofers as additions that let the E12 reproduce high level music program.
The d&b audiotechnik E12 weighs 16 kg (35 lb).
Trianze Tech supplies the d&b audiotechnik E12 NLT4 F/M in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
