d&b audiotechnik U7N: Networked 2 Way Loudspeaker with Dual 8 Inch Drivers, Milan, PoE++ and 80 x 55 Degree Horn
Model
:
U7N
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
d&b audiotechnik U7N Networked 2 Way Loudspeaker
The d&b audiotechnik U7N is a networked 2 way loudspeaker with dual 8 inch bipole drivers and a 1.26 inch compression driver on a rotatable 80 x 55 degree horn for directivity control and efficiency. Bass reflex porting extends the low frequency response while 80 degree horizontal and 55 degree vertical directivity are maintained from 500 Hz upward, and tool free horn rotation allows quick deployment changes. A hybrid power topology runs on AC, PoE++ or both at once, with dual cable redundancy for mission critical installations. Trianze Tech supplies the U7N in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 2 x 8 inch neodymium drivers with 1.26 inch compression driver
- 80 x 55 degree tool free rotatable horn
- 136 dB SPLmax
- Runs on AC, PoE++ or both simultaneously
- Milan input, 1 stream with up to 8 channels at 48/96 kHz
- Dual cable redundancy for mission critical installs
Technical Specifications:
| Spec | Value |
|---|---|
| Model | U7N |
| Type | Networked 2 way loudspeaker |
| Frequency Response | 55 Hz to 18 kHz (standard), 105 Hz to 18 kHz (CUT mode), -5 dB |
| Max SPL | 136 dB |
| Dispersion | 80 x 55 degrees, rotatable |
| Components | 2 x 8 inch neodymium drivers, 1 x 1.26 inch compression driver with 2.4 inch coil |
| DSP | 2 user definable 16 band equalizers, delay 1.1 ms to 1 s, analog input latency 1.1 ms |
| Inputs | 3 pin XLR analog input and link, Milan (1 stream, up to 8 channels) |
| Network | 2 x RJ45 etherCON, integrated 2 port switch, 100 Mbit/1 Gbit |
| Mains | powerCON TRUE1 TOP In and Thru, 100 to 240 V, 50 to 60 Hz |
| Dimensions (H x W x D) | 611 x 268 x 355 mm |
| Weight | 19.4 kg (42.8 lb) |
Why Buy the d&b audiotechnik U7N from Trianze Tech?
- Genuine d&b audiotechnik equipment with local UAE support from the Trianze Tech audio team
- System design help matching the U7N with compatible d&b loudspeakers, amplifiers and rigging
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Pre-sales guidance for touring, live event and installed sound projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The d&b audiotechnik U7N runs on AC (100 to 240 V), PoE++, or both simultaneously, and single cable operation carries power, signal, control and monitoring.
The d&b audiotechnik U7N has a tool free, rotatable 80 x 55 degree horn, with directivity maintained from 500 Hz upward.
The d&b audiotechnik U7N reaches 136 dB maximum SPL with a frequency response of 55 Hz to 18 kHz (-5 dB standard).
The d&b audiotechnik U7N uses 2 x 8 inch neodymium drivers in a bipole arrangement and a 1.26 inch exit compression driver with a 2.4 inch coil.
The d&b audiotechnik U7N weighs 19.4 kg (42.8 lb) and measures 611 x 268 x 355 mm (24 x 10.6 x 14 inches).
Trianze Tech supplies the d&b audiotechnik U7N in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
