Shure MXA901B-R: 13.5 Inch Round Ceiling Array Microphone with Single Zone Automatic Coverage and IntelliMix DSP, Black
Model
:
MXA901B-R
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure MXA901B-R: 13.5 Inch Round Ceiling Array Microphone with Single Zone Automatic Coverage and IntelliMix DSP, Black
The Shure MXA901B-R is the sleekest ceiling array microphone in the Microflex Advance range, giving AV conferencing audio in a discreet 13.5 inch round form factor that suits any interior. Single Zone Automatic Coverage captures talkers with no setup, one unit serves a smaller room and several can be combined in larger spaces, and onboard IntelliMix DSP delivers echo- and noise-free audio. It is ideal for boardrooms and meeting rooms across Dubai, Abu Dhabi and the UAE.
Key Features
- Single Zone Automatic Coverage of a 20 x 20 foot area out of the box; maximum recommended mounting height is 12 feet (3.7 m)
- Onboard IntelliMix DSP with automatic mixing, echo cancellation, noise reduction and gain control
- 13.5 inch round form factor
- Certified for use with Teams and Zoom
- Shure Audio Encryption keeps meeting content secure
- Next-generation array architecture for natural speech and enhanced directional pickup
Technical Specifications
| Spec | Detail |
|---|---|
| Model / Part Number | MXA901B-R |
| Coverage | Single-zone automatic, 20 x 20 ft (6.1 x 6.1 m) |
| Microphone Elements | 85 MEMS |
| Frequency Response | 100 Hz to 20 kHz |
| Sensitivity | -4.4 dBFS/Pa at 1 kHz |
| Maximum SPL | 98.4 dB SPL |
| Signal-to-Noise Ratio | 67.1 dB A-weighted (94 dB SPL, 1 kHz) |
| Self Noise / Dynamic Range | 26.9 dB SPL-A / 71.5 dB |
| Latency | 33.5 ms, excluding Dante latency |
| AEC Tail Length | Up to 250 ms |
| Power | PoE Class 0, 10.1 W maximum |
| Ratings | UL2043 plenum, IP5X dust protected |
| Size / Weight | 13.5 in round, 1.64 in high / 5 lb |
Why Buy the Shure MXA901B-R from Trianze Tech?
Trianze Tech is a UAE-based Pro AV distributor with local stock in Dubai, removing the delays of international shipping for conferencing audio.
- Genuine Shure stock sourced through authorized distribution channels
- Microflex Advance system design advice across Dubai, Abu Dhabi and the GCC
- Finish and mounting checking before you order
- Local UAE warranty backing and after-sales support
- Volume pricing available for integrators and enterprises
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Shure MXA901B-R is a 13.5 inch round, black ceiling array microphone from the Microflex Advance range. Shure describes it as its sleekest ceiling array yet, giving AV conferencing audio in a discreet form factor with natural speech and enhanced directional pickup.
Single Zone Automatic Coverage covers a 20 x 20 foot (6.1 x 6.1 meter) area with no setup, and the maximum recommended mounting height is 12 feet (3.7 m). One unit suits a smaller room, or several can be used in larger spaces.
Onboard IntelliMix DSP provides automatic mixing, acoustic echo cancellation (tail length up to 250 ms), noise reduction, automatic gain control, compressor, delay and a 4-band parametric EQ. Latency is 33.5 ms excluding Dante latency, and the array is certified for use with Teams and Zoom.
The MXA901B-R has 85 MEMS elements, a 100 Hz to 20 kHz frequency response, sensitivity of -4.4 dBFS/Pa at 1 kHz, maximum SPL of 98.4 dB SPL, signal-to-noise ratio of 67.1 dB A-weighted, self noise of 26.9 dB SPL-A and 71.5 dB dynamic range.
It uses PoE Class 0 at 10.1 W maximum over an RJ45 connection (Cat 5e or higher, shielded recommended), is plenum rated to UL2043 and IP5X dust protected, and weighs 5 lb. The 13.5 inch round unit is 1.64 inches high and is secured with Shure Audio Encryption.
Trianze Tech stocks the Shure MXA901B-R in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
