Q-SYS NM-T1-BK: Boundary Microphone with Beamforming
Model
:
NM-T1-BK
Buying guides for this product
- Ceiling, Boundary or Gooseneck Meeting Room Microphones
- Logitech Sight vs DSP Ceiling Microphones
- Video Conferencing Room Cost Factors
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Q-SYS NM-T1-BK at a Glance
- Brand
- Q-SYS
- Model
- NM-T1-BK
- Category
- Microphones
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Q-SYS NM-T1-BK Overview
The Q-SYS NM Series NM-T1 is a tabletop network PoE microphone native to Q-SYS and ideal for the collaboration space. The microphone features advanced beamforming technology that ensures optimal clarity and separation for all surrounding talkers. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- The microphone features advanced beamforming technology that ensures optimal clarity and separation for all surrounding talkers.
- Audio: Polar pattern: Superdirective
- Audio: Pickup Range: 3-9 ft (1-3 m)
- Audio: Microphone elements: 16x MEMS microphone elements
- Audio: Network input channels required (per NM-T1): 1x network audio stream and 16x network audio channels
- Audio: Frequency response: 100 Hz to 16 kHz, +/-3 dB
Technical Specifications:
| Spec | Value |
|---|---|
| Model | NM-T1-BK |
| Brand | Q-SYS |
| Audio: Polar pattern | Superdirective |
| Audio: Pickup Range | 3-9 ft (1-3 m) |
| Audio: Microphone elements | 16x MEMS microphone elements |
| Audio: Network input channels required (per NM-T1) | 1x network audio stream and 16x network audio channels |
| Audio: Frequency response | 100 Hz to 16 kHz, +/-3 dB |
| Audio: Sampling rate | 16 kHz wideband / 48 kHz fullband |
| Audio: Bit depth | 24 bit |
| Audio: Sensitivity | -36 dBFS (94 dB SPL) |
| Audio: Maximum SPL (1 kHz @ 1% THD) | 118 dB SPL |
| Audio: Dynamic range | 95 dB |
| Audio: Signal-to-Noise ratio | 65 dB (48 kHz) 66 dB (16 kHz) |
| Audio: Self noise | 28 dB SPL (48 kHz) 28 dB SPL (16 kHz) |
| Audio: Latency | 4 ms |
| Power: Power requirements | Power over Ethernet (PoE),Type 1 Class 2 |
| Power: Power consumption | <6.5 W |
| Power: Connector type | RJ45 |
| General Specifications: Dimensions | 4.21 x 1.1 in (107 x 28 mm) |
| General Specifications: Weight | 1.5 lbs (0.68 kg) |
| General Specifications: Included accessories | Mounting stem, Strain relief cap, CAT6 cable (10 ft / 3 m) |
Why Buy the Q-SYS NM-T1-BK from Trianze Tech?
- Genuine Q-SYS product supplied by Trianze Tech with local UAE support
- Pre-sales help designing the Q-SYS system around the NM-T1-BK
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Q-SYS NM-T1-BK: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The Q-SYS NM Series NM-T1 is a tabletop network PoE microphone native to Q-SYS and ideal for the collaboration space. The microphone features advanced beamforming technology that ensures optimal clarity and separation for all surrounding talkers.
For the Q-SYS NM-T1-BK, Q-SYS lists the following. Audio: Network input channels required (per NM-T1): 1x network audio stream and 16x network audio channels; Power: Connector type: RJ45.
For the Q-SYS NM-T1-BK, Q-SYS lists the following. Audio: Network input channels required (per NM-T1): 1x network audio stream and 16x network audio channels; Audio: Frequency response: 100 Hz to 16 kHz, +/-3 dB; Audio: Sampling rate: 16 kHz wideband / 48 kHz fullband; Audio: Sensitivity: -36 dBFS (94 dB SPL); Audio: Maximum SPL (1 kHz @ 1% THD): 118 dB SPL.
For the Q-SYS NM-T1-BK, Q-SYS lists the following. Power: Power requirements: Power over Ethernet (PoE),Type 1 Class 2; Power: Power consumption: <6.5 W; Power: Connector type: RJ45.
For the Q-SYS NM-T1-BK, Q-SYS lists the following. General Specifications: Dimensions: 4.21 x 1.1 in (107 x 28 mm); General Specifications: Weight: 1.5 lbs (0.68 kg).
Trianze Tech stocks the Q-SYS NM-T1-BK in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
