Crestron DM-NVX-D30 DM NVX ® 4K60 4:4:4 HDR Network AV Decoder
Model
:
DM-NVX-D30
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 or Chat on WhatsApp
Crestron DM NVX DM-NVX-D30 4K60 4:4:4 HDR Network AV Decoder
The DM-NVX-D30 is a compact AV over IP decoder built to receive 4K60 4:4:4 video over standard gigabit Ethernet with no perceptible latency or loss of quality, using standard network switches and CAT5e UTP wiring. Powered via PoE+ for a single cable installation, it is engineered for conference rooms, classrooms, and campus wide content distribution across Dubai, Abu Dhabi, and the wider GCC.
Key Features
- 4K60 4:4:4 video decoding over standard gigabit Ethernet
- HDR10, HDR10+, and Dolby Vision video support with Pixel Perfect Processing technology
- Enterprise grade security including 802.1X, Active Directory, TLS, and AES-128
- One HDMI output with image preview and background image display
- Analog audio de-embedding, 7.1 surround sound, and AES67 audio support
- Copper Ethernet connectivity with PoE+ support
- Automatic point to point connectivity direct from a DM NVX encoder
- Device control via RS-232, IR, and CEC
- Compact, surface mountable design
Technical Specifications
| Specification | Detail |
|---|---|
| Video Resolutions | Up to 4096x2160 at 60Hz (DCI 4K60), 4:4:4 color sampling, HDR10, HDR10+, Dolby Vision, Deep Color |
| Audio Formats | Multichannel up to 8-channel LPCM or encoded HBR 7.1 surround sound |
| Streaming Protocols | RTP, SDP, MPEG-2 transport stream container, multicast via secure RTSP |
| Copy Protection | HDCP 2.3, AES-128, PKI |
| Output Signal Types | HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, 4K60 4:4:4 support, DVI compatible |
| Digital Audio Formats | Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS HD Master Audio, DTS:X, LPCM up to 8 channels |
| Analog Performance | Frequency response 20 Hz to 20 kHz plus or minus 0.5 dB, S/N ratio greater than 95 dB, THD+N less than 0.005% |
| Analog Output Volume Adjustment | -80 to +20 dB |
| Ethernet | 100/1000 Mbps, auto-switching, TCP/IP, UDP/IP, SSL, TLS, SSH, SFTP, IEEE 802.1X, IPv4 or IPv6 |
| USB | USB 2.0 computer console for setup, Micro USB connector |
| RS-232 | 2-way device control up to 115.2k baud with hardware and software handshaking |
| IR/Serial | 2x IR/Serial ports, IR output up to 1.1 MHz or serial TTL/RS-232 up to 19200 baud |
| Ethernet Connector | 1x RJ-45, 100BASE-TX/1000BASE-T, PoE+ PD port, IEEE 802.3at Type 2 Class 4 compliant |
| HDMI Output | 1x HDMI Type A connector, digital video/audio output, DVI compatible |
| Audio Output | 1x 5-pin 3.5mm detachable terminal block, balanced/unbalanced stereo line level |
| Power Input | PoE+ (IEEE 802.3at Type 2 Class 4, 25.5 W) or optional PW-2412WU power pack, 24VDC 1.25A |
| Power Consumption | 16 W typical |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Humidity | 10% to 90% RH, non-condensing |
| Enclosure | Metal, black finish, fan cooled, freestanding, surface mount, or single rack rail mounting |
| Dimensions | 5.41 in H x 9.27 in W x 1.15 in D |
| Weight | 1.7 lb (0.77 kg) |
| Compliance | Bureau Veritas Listed for US and Canada, IC, CE, FCC Part 15 Class B digital device |
Why Buy the Crestron DM-NVX-D30 from Trianze Tech?
- Genuine Crestron stock with manufacturer warranty
- UAE based inventory for fast Dubai and GCC wide delivery
- Pre sales consultation on AV over IP system design
- Professional installation and commissioning available
- Ongoing technical support from a Dubai based AV integration team
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Trianze Tech supplies the Crestron DM-NVX-D30 as genuine, manufacturer warranted stock from local Dubai inventory. Purchasing through Trianze Tech means authentic hardware, full UAE warranty coverage, AV over IP design consultation, and installation support across Dubai, Abu Dhabi, and the wider GCC. Contact the team via WhatsApp at +971 58 161 3661 for a quote.
The DM-NVX-D30 is powered via PoE+ (IEEE 802.3at Type 2 Class 4, 25.5 W) from a compatible switch or Crestron DM-PSU-ULTRA-MIDSPAN, delivering both data and power over a single Ethernet cable. An optional PW-2412WU power pack is available separately if PoE+ is not present on the network.
Yes. The DM-NVX-D30 supports automatic point to point connectivity, allowing its 1000BASE-T Ethernet port to connect directly to a DM NVX 4K60 4:4:4 encoder without an intermediate switch. The device automatically detects this direct connection and operates without additional configuration, though a control system is still required for CEC, RS-232, and IR control.
Yes. The DM-NVX-D30 supports lossless transport of 7.1 surround sound audio formats including Dolby TrueHD, Dolby Atmos, DTS HD, and DTS:X, alongside uncompressed linear PCM and AES67 audio embedding and de-embedding for integration with Crestron DSPs or third party audio devices.
The DM-NVX-D30 has a low profile design that mounts to a flat surface or rack rail and fits easily behind a flat panel display, above a ceiling mounted projector, or inside an AV cart or equipment cabinet, with all connectors and LEDs accessible from the front and rear for a clean, serviceable installation.
