Shure UA845: UHF Antenna and Power Distribution System for Four Receivers, US Version 500 to 900 MHz
Model
:
UA845 (US version)
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure UA845 Antenna and Power Distribution System
The Shure UA845 is a UHF antenna distribution amplifier that feeds one pair of antennas to four receivers such as the Shure U4S, U4D or UC4, amplifying the signal to make up for splitting loss. Cascade ports add a fifth receiver or a second UA845, and power connectors run Shure UHF and UC receivers directly, for wireless racks across Dubai, Abu Dhabi and the UAE and GCC.
Key Features:
- Four receivers share one antenna pair
- Cascade connectors for a fifth receiver or second UA845
- Power connectors run Shure UHF and UC receivers
- Insertion loss compensation
- 1 RU rack chassis
Technical Specifications:
| Spec | Value |
|---|---|
| Frequency Range | 500 to 900 MHz (US version) |
| Outputs | 4 BNC plus cascade port |
| Gain | 3 dB typical to outputs 1 to 4; 1 dB typical to cascade |
| Impedance | 50 ohm |
| Power Consumption | 15 W typical per unit |
| Dimensions | 44.5 x 482.6 x 295.3 mm |
| Weight | 3.32 kg |
Why Buy the Shure UA845 from Trianze Tech?
- Shure RF accessory with local support
- Fast delivery across Dubai, Abu Dhabi and the UAE and GCC
- RF and antenna planning help
- Dedicated AV support team
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The UA845 distributes the signal from one pair of antennas to four Shure receivers, amplifying it to compensate for splitting loss, and can also power the receivers.
Shure lists the U4S, U4D and UC4 receivers, plus other Shure UHF and UC wireless receivers in range.
This US version covers 500 to 900 MHz. Confirm with Trianze Tech that it matches your receiver band.
Yes. Its cascade connectors feed a fifth receiver or a second UA845.
The UA845 is a 1 RU unit measuring 44.5 x 482.6 x 295.3 mm and weighing 3.32 kg.
Trianze Tech stocks the Shure UA845 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
