Shure UR4D J5: UHF-R Dual Channel Diversity Wireless Receiver, J5 Band 578 to 638 MHz
Model
:
UR4D J5
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure UR4D J5 UHF-R Dual Receiver
The Shure UR4D J5 is a UHF-R dual channel diversity receiver tuning 578 to 638 MHz, with up to 2400 selectable frequencies, Track Tuning filtering, networked frequency selection and RF distribution ports that let up to 10 receivers share one antenna pair. It suits touring, theatre and broadcast racks across Dubai, Abu Dhabi and the UAE and GCC.
Key Features:
- Two channels with microprocessor diversity
- Up to 2400 selectable frequencies
- Track Tuning filtering
- RF distribution ports for up to 10 receivers
- USB and Ethernet with Wireless Workbench
Technical Specifications:
| Spec | Value |
|---|---|
| RF Band | J5, 578 to 638 MHz |
| Audio Output | +24 dBu line, -6 dBu mic |
| Output Impedance | 200 ohm balanced (150 ohm mic) |
| RF Sensitivity | -107 dBm typical for 12 dB SINAD |
| Image Rejection | 110 dB typical |
| Power | 90 to 230 V AC, 12 to 16 W |
| Housing | Galvanised steel |
| Dimensions | 44 x 483 x 366 mm |
| Weight | 5.1 kg |
Why Buy the Shure UR4D J5 from Trianze Tech?
- Shure UHF-R receiver with local support
- Fast delivery across Dubai, Abu Dhabi and the UAE and GCC
- Frequency planning help
- Dedicated AV support team
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The UR4D J5 tunes 578 to 638 MHz, with up to 2400 selectable frequencies.
The UR4D is a dual receiver, so it handles two UHF-R transmitters at once.
Yes. Its RF distribution ports let up to 10 receivers share a single pair of antennas.
Yes. It has USB and Ethernet and works with Shure Wireless Workbench for monitoring and frequency coordination.
It runs on 90 to 230 V AC mains and draws 12 to 16 W.
Trianze Tech stocks the Shure UR4D J5 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
