Shure ULXD8-J50: Wireless Gooseneck Microphone Base Transmitter for ULXD and QLXD Systems, J50 Band, 572 to 636 MHz
The Shure ULXD8 Gooseneck Base Transmitter offers a flexible gooseneck microphone form factor for meetings and events where wired microphones are impractical. Paired with a ULX-D or QLX-D digital receiver it creates a system with low latency, long transmission range and high channel count for large meeting venues where live sound reinforcement is required, across Dubai, Abu Dhabi and the UAE. This listing is the J50 band, 572 to 636 MHz.
Key Features
- Designed for Shure Microflex MX405, MX410 and MX415 gooseneck microphones, plus MX410DF and MX415DF Dualflex versions
- Very low latency for meetings that require live sound reinforcement
- Transmission range up to 300 feet (100 meters)
- Up to 200 ULXD8 transmitters with just one pair of receiving antennas
- Compatible with ULX-D and QLX-D digital receivers
- SB900 or SB900A rechargeable batteries, up to 9 hours at 10 mW, or AA batteries
- Works with SBC450 (4-bay) and SBC850 (8-bay) networked charging stations
- Configurable mute button (Toggle, Push-to-Mute, Push-to-Talk, disabled) and mute LED behavior
- Adjustable RF power, high-pass filter and power lock
Technical Specifications
| Spec | Detail |
|---|---|
| Model / Part Number | ULXD8-J50 |
| Frequency Band | J50, 572 to 636 MHz |
| RF Power | 1, 10 or 20 mW |
| Modulation / Antenna | Shure proprietary digital / integrated PIFA, 50 ohms |
| Occupied Bandwidth | Under 200 kHz |
| Gain Adjustment | 0 to 21 dB in 3 dB steps |
| Audio Input | 6-pin connector for MX405, MX410 and MX415; unbalanced; above 20 kilohms |
| Battery Runtime at 10 mW | SB900: up to 9 hours; AA: up to 8 hours 20 minutes |
| Size / Weight | 136.94 x 78.27 x 40.77 mm (5.39 x 3.08 x 1.60 in) / 293 g with AA batteries |
| Operating Temperature | 0 to 45 C (32 to 113 F) |
| Housing | Molded plastic |
Why Buy the Shure ULXD8-J50 from Trianze Tech?
Trianze Tech is a UAE-based Pro AV distributor with local stock in Dubai, removing the delays of international shipping for professional wireless.
- Genuine Shure stock sourced through authorized distribution channels
- Meeting room wireless design and band planning across Dubai, Abu Dhabi and the GCC
- Band and receiver checking before you order
- Local UAE warranty backing and after-sales support
- Volume pricing available for integrators and venues
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Shure ULXD8-J50 is a gooseneck base transmitter that gives a flexible wireless gooseneck microphone for meetings and events where wired microphones are impractical. It pairs with a ULX-D or QLX-D digital receiver and this listing is the J50 band, 572 to 636 MHz.
The ULXD8 is designed for Shure Microflex MX405, MX410 and MX415 gooseneck microphones, as well as the MX410DF and MX415DF Dualflex versions. Its input is a 6-pin connector for the MX405, MX410 and MX415.
At 10 mW, the ULXD8 runs up to 9 hours on a Shure SB900 or SB900A rechargeable Li-ion battery and up to 8 hours 20 minutes on AA batteries.
The ULXD8 has a long transmission range of up to 300 feet (100 meters). It is compatible with the full line of Shure antennas and distribution components, allowing up to 200 ULXD8 gooseneck base transmitters to be used with just one pair of receiving antennas.
The mute button can be set to Toggle, Push-to-Mute, Push-to-Talk or disabled, with configurable mute LED behavior. RF power is selectable at 1, 10 or 20 mW, with an adjustable high-pass filter, power lock and 0 to 21 dB of gain in 3 dB steps.
