Shure UA844+V/LC: VHF Five Way Antenna and Power Distribution for ULX-D and QLX-D Receivers
Model
:
UA844+V/LC
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure UA844+V/LC Antenna Distribution
The Shure UA844+V/LC is a VHF antenna distribution system that splits one pair of antennas to up to five VHF ULX-D or QLX-D receivers, amplifying RF to make up for splitting loss. It also powers the receivers, keeping racks tidy in venues across Dubai, Abu Dhabi and the UAE and GCC.
Key Features:
- Five way VHF RF output
- For VHF ULX-D and QLX-D receivers
- DC power feeds for receivers and antenna bias
- Rack and front antenna mounting hardware
Technical Specifications:
| Spec | Value |
|---|---|
| Band | VHF |
| Power Feeds | 4 DC outputs for receivers (15 V, 2.5 A max) |
| Antenna Bias | 12 V, 300 mA max |
| Outputs | Five way RF output |
| Expansion | Up to 5 systems in a two tier configuration |
| Compatible Receivers | VHF ULX-D and QLX-D |
Why Buy the Shure UA844+V/LC from Trianze Tech?
- Genuine Shure product with local support
- Fast delivery across Dubai, Abu Dhabi and the UAE and GCC
- Help choosing compatible parts and accessories
- Dedicated AV support team
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
One unit supports up to five wireless receivers, and up to five units can be used in a two tier setup.
It supports VHF versions of ULX-D and QLX-D digital wireless receivers.
Yes. It has 4 DC feeds for receivers at 15 V, 2.5 A max, plus 12 V, 300 mA antenna bias.
LC means less cable: it includes four non locking DC cables for QLXD4 but not the full set of receiver antenna cables, so use the BNC cables supplied with your ULX-D or QLX-D receivers.
No. The V model is for VHF systems; the UA844+SWB is the wideband UHF version.
Trianze Tech offers the Shure UA844+V/LC in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
