Shure P3TR112TW-J13: PSM300 Twin Pack Wireless Personal Monitor System with P3T Transmitter, 2 P3R Bodypacks and Earphones, J13 Band, 566 to 590 MHz
Model
:
P3TR112TW-J13
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Shure P3TR112TW-J13: PSM300 Twin Pack Wireless Personal Monitor System with P3T Transmitter, 2 P3R Bodypacks and Earphones, J13 Band, 566 to 590 MHz
The Shure PSM300 Stereo Personal Monitor System delivers detailed 24-bit digital audio and reliable wireless freedom for performers on stage. This Twin Pack has a half-rack single-channel P3T transmitter with rackmount kit and two P3R bodypack receivers with earphones, with patented Audio Reference Companding, over 300 ft (90 m) of range, one-touch frequency scan and IR sync, and MixMode or stereo mode for a personal mix. It is available in Dubai, Abu Dhabi and across the UAE. This listing is the J13 band, 566 to 590 MHz.
Key Features
- Sends two channels of audio wirelessly to performers on stage
- 24-bit digital audio with patented Audio Reference Companding
- Up to 90 dB signal to noise ratio and wide stereo separation
- Solid analog RF over a 300 ft (90 m) range
- Personal mix on the bodypack with MixMode or stereo mode
- Frequency scan and IR sync find and assign a clean channel
- Half-rack single-channel transmitter with included rackmount kit
Technical Specifications
| Spec | Detail |
|---|---|
| Model / Part Number | P3TR112TW-J13 |
| Frequency Band | J13, 566 to 590 MHz |
| Tuning Bandwidth | 24 MHz maximum, up to 15 compatible frequencies |
| Operating Range | 90 m (300 ft), environment dependent |
| Audio Frequency Response | 38 Hz to 15 kHz |
| Signal to Noise Ratio | 90 dB (A-weighted, typical) |
| THD | Below 0.5% (typical) |
| Spurious Rejection / Stability | Above 80 dB typical / 2.5 ppm |
| Modulation | FM, MPX stereo, 19 kHz pilot tone |
| Operating Temperature | -18 to 63 C |
Why Buy the Shure P3TR112TW-J13 from Trianze Tech?
Trianze Tech is a UAE-based Pro AV distributor with local stock in Dubai, removing the delays of international shipping for personal monitor systems.
- Genuine Shure stock sourced through authorized distribution channels
- Band matching and system advice before you order
- IEM system advice across Dubai, Abu Dhabi and the GCC
- Local UAE warranty backing and after-sales support
- Volume pricing available for churches, venues and touring teams
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
It is a PSM300 stereo personal monitor Twin Pack for two performers: a half-rack single-channel P3T transmitter with rackmount kit and two P3R bodypack receivers with earphones (the 112 in the part number refers to the SE112 earphones). This listing is the J13 band, 566 to 590 MHz.
Coverage is 300 ft (90 m), environment dependent, with 24-bit digital audio, patented Audio Reference Companding and up to 90 dB signal to noise ratio. Audio frequency response is 38 Hz to 15 kHz and THD is below 0.5% typical.
With MixMode, the performer adjusts the level of two independent audio channels, or uses stereo mode to adjust left/right balance, to create a personal mix from the two channels sent by the transmitter.
One-touch frequency scan finds a clean channel and IR sync assigns it to the bodypack. The transmitter is half-rack with an included rackmount kit and up to 15 compatible frequencies per band within a 24 MHz maximum tuning bandwidth.
The J13 band covers 566 to 590 MHz. Wireless frequency use is subject to local regulation, so Trianze Tech confirms the correct band and matching bodypacks for your project before you order.
Trianze Tech stocks the Shure P3TR112TW-J13 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
