Shure AD4DUS-B: Axient Digital 2-Channel Receiver, US Power, B Band
Model
:
AD4DUS-B
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure AD4DUS-B Axient Digital 2-Channel Receiver
The Shure AD4DUS-B is a 2-channel Axient Digital receiver in a rugged single rack unit, built for televised live performances, award shows, corporate events and secure government installations across Dubai, Abu Dhabi and the UAE and GCC. It ships with a US-market cable and mounting accessory set.
Key Features:
- 166 MHz ultrawide tuning range covering the entire B band
- True digital diversity reception
- Low 2 to 2.9 ms selectable latency
- AES-256 encrypted transmission
- Compatible with AD1, ADX1, ADX1M, AD2, ADX2 and ADX2FD transmitters
- XLR/AES3 plus AES67/Dante outputs, Dante Cue and Dante Browse monitoring
Technical Specifications:
| Spec | Value |
|---|---|
| Channels | 2 |
| Frequency Band | B (606 to 810 MHz) |
| RF Sensitivity | Approximately -98 dBm |
| Adjacent Channel Isolation | Greater than 70 dB |
| Dimensions / Weight | 483 x 44 x 333 mm, 4.6 kg without antennas |
| Max Transmitters per Band | 120 (standard), up to 47 per 6 MHz TV channel in HD mode |
Why Buy the Shure AD4DUS-B from Trianze Tech?
- Genuine Shure Axient Digital receiver backed by manufacturer warranty support
- Fast delivery across Dubai, Abu Dhabi and the UAE and GCC
- Expert guidance on Axient Digital system design and band planning
- Competitive pricing with dedicated AV support
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Shure AD4DUS-B is compatible with the full Axient Digital transmitter range: AD1, ADX1, ADX1M, AD2, ADX2 and ADX2FD, as long as they are tuned to the same B band.
The AD4DUS-B operates on the B band, 606 to 810 MHz, a single 166 MHz ultrawide tuning bandwidth.
In standard mode an Axient Digital system built around AD4DUS-B receivers supports over 120 simultaneous channels; in High Density mode it can support up to 47 active transmitters per 6 MHz TV channel.
The AD4DUS-B offers low latency of 2 to 2.9 ms, selectable, with true digital diversity reception and AES-256 encrypted transmission.
The AD4DUS-B weighs 4.6 kg (10.1 lb) without antennas, measuring 483 x 44 x 333 mm (19 x 1.7 x 13.1 in) in a 1 RU rackmount steel housing.
Trianze Tech stocks the Shure AD4DUS-B in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
