Shure ANI22-XLR: 2-Channel In/2-Channel Out XLR Audio Network Interface with Dante
Model
:
ANI22-XLR
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Shure ANI22-XLR Dante Audio Network Interface
The Shure ANI22-XLR bridges 2 analog XLR mic or line inputs and 2 analog XLR outputs onto a Dante audio network, giving AV integrators across Dubai, Abu Dhabi and the UAE and GCC an easy way to add analog gear to a Dante-based boardroom or conferencing system.
Key Features:
- 2 analog XLR inputs and 2 analog XLR outputs onto Dante
- Power over Ethernet (PoE) eliminates the need for an outboard power supply
- Browser-based HTML5 setup and control, no software install required
- Per-channel 4-band parametric EQ, mute, limiter and up to 140 dB gain range
- Compact form factor mounts without a full equipment rack
Technical Specifications:
| Spec | Value |
|---|---|
| Analog I/O | 2x XLR in, 2x XLR out |
| Dante Connection | 1x RJ45, 2 in / 2 out channels |
| Sampling Rate | 24-bit / 48 kHz |
| Latency | 0.35 ms analog to Dante, 0.71 ms Dante to analog |
| Dynamic Range | 113 dB, A-weighted |
| Frequency Response | 20 Hz to 20 kHz +/- 1 dB |
| Power | PoE, Class 0, 11 W maximum |
| Dimensions | 4 x 14 x 12.8 cm (H x W x D) |
| Weight | 672 g (1.5 lb) |
Why Buy the Shure ANI22-XLR from Trianze Tech?
- Genuine Shure Dante network hardware backed by manufacturer warranty support
- Fast delivery across Dubai, Abu Dhabi and the UAE and GCC
- Expert guidance on integrating analog gear into a Dante boardroom system
- Competitive pricing with dedicated AV support
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Shure ANI22-XLR is a Dante audio network interface that converts 2 analog XLR mic or line inputs onto a Dante network and converts 2 Dante channels back to analog XLR outputs, letting analog microphones and amplifiers join a Dante-based AV system.
No. The ANI22-XLR is powered entirely over Power over Ethernet (PoE, Class 0, PoE Plus compatible), drawing up to 11 W, so it needs only a single Ethernet cable from a PoE switch or injector for both power and Dante networking.
The ANI22-XLR adds 0.35 ms converting analog to Dante and 0.71 ms converting Dante back to analog, not including the network's own Dante latency, at 24-bit/48 kHz sampling.
The ANI22-XLR is configured through a built-in HTML5 web application accessible from any browser on the same network, with per-channel controls including a 4-band parametric EQ on Dante channels, mute, limiter, and up to 140 dB of gain range.
The Shure ANI22-XLR has a 113 dB dynamic range (A-weighted, 20 Hz to 20 kHz) and an analog gain range of 51 dB adjustable in 3 dB steps, with less than 0.05% THD at 1 kHz with 0 dBV input and 0 dB gain.
Trianze Tech stocks the Shure ANI22-XLR in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
