Q-SYS NL-P4-WH: PoE Pendant Loudspeaker, Color: White
Model
:
NL-P4-WH
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Q-SYS NL-P4-WH at a Glance
- Brand
- Q-SYS
- Model
- NL-P4-WH
- Category
- Speakers
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Q-SYS NL-P4-WH Overview
The Q-SYS NL-P4 is a network PoE loudspeaker that delivers clear speech and music reproduction natively to Q-SYS. The pendant-mount loudspeaker features a four-inch, full-range driver, optimized for open-ceiling installations. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- The pendant-mount loudspeaker features a four-inch, full-range driver, optimized for open-ceiling installations.
- Loudspeaker type: Network PoE pendant-mount loudspeaker for Q-SYS
- Driver: 4-in (101.6 mm) full-range, paper cone woofer, ferrite magnet
- Effective frequency range: 90 Hz to 20 kHz
- Rated noise power / voltage (W rms): 12 W (PoE), 24 W (PoE+)
- Rated coverage (-6 dB): 100 degrees
Technical Specifications:
| Spec | Value |
|---|---|
| Model | NL-P4-WH |
| Brand | Q-SYS |
| Loudspeaker type | Network PoE pendant-mount loudspeaker for Q-SYS |
| Driver | 4-in (101.6 mm) full-range, paper cone woofer, ferrite magnet |
| Effective frequency range | 90 Hz to 20 kHz |
| Rated noise power / voltage (W rms) | 12 W (PoE), 24 W (PoE+) |
| Rated coverage (-6 dB) | 100 degrees |
| Directivity factor | 5.3 |
| Directivity index | 7.2 dB |
| Maximum continuous SPL | 94 dB (PoE), 97 dB (PoE+) |
| Maximum peak SPL | 108 dB (PoE), 111 dB (PoE+) |
| Input connector type | RJ45, Q-LAN |
| Enclosure material | ABS baffle on powder steel back can |
| Grille material | Powder coated steel |
| Ingress protection | IP34 |
| Net Weight | 2.88 lbs (1.31 kg) |
| Product dimensions (diameter x height) | 6.81 x 7.83 in (173 x 199 mm) |
| Operating environment | Designed for indoor use, IP34 ingress protection for weather protected outdoor spaces |
| Operating temperature range | -20 degrees to 50 C |
| Included accessories | Quick-link cable assembly (length: 128 in / 3.25 m; thickness: 2 mm), slip-lock fastener, sealable input cover and screws, snapfit magnetic grille |
| Safety agency | UL/IEC 62368-1 |
| Power requirements | PoE (Type 1 Class 3) or PoE+ (Type 2 Class 4) |
Why Buy the Q-SYS NL-P4-WH from Trianze Tech?
- Genuine Q-SYS product supplied by Trianze Tech with local UAE support
- Pre-sales help designing the Q-SYS system around the NL-P4-WH
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Q-SYS NL-P4-WH: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The Q-SYS NL-P4 is a network PoE loudspeaker that delivers clear speech and music reproduction natively to Q-SYS. The pendant-mount loudspeaker features a four-inch, full-range driver, optimized for open-ceiling installations.
For the Q-SYS NL-P4-WH, Q-SYS lists the following. Input connector type: RJ45, Q-LAN.
For the Q-SYS NL-P4-WH, Q-SYS lists the following. Effective frequency range: 90 Hz to 20 kHz; Rated noise power / voltage (W rms): 12 W (PoE), 24 W (PoE+); Rated coverage (-6 dB): 100 degrees; Maximum continuous SPL: 94 dB (PoE), 97 dB (PoE+); Maximum peak SPL: 108 dB (PoE), 111 dB (PoE+).
For the Q-SYS NL-P4-WH, Q-SYS lists the following. Rated noise power / voltage (W rms): 12 W (PoE), 24 W (PoE+); Power requirements: PoE (Type 1 Class 3) or PoE+ (Type 2 Class 4).
For the Q-SYS NL-P4-WH, Q-SYS lists the following. Net Weight: 2.88 lbs (1.31 kg); Product dimensions (diameter x height): 6.81 x 7.83 in (173 x 199 mm); Operating temperature range: -20 degrees to 50 C.
Trianze Tech stocks the Q-SYS NL-P4-WH in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
