Q-SYS DTH1620: 16-Channel Dante Network Amplifier Themed Entertainment
Model
:
DTH1620
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Q-SYS DTH1620 at a Glance
- Brand
- Q-SYS
- Model
- DTH1620
- Category
- Power Amplifiers
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Q-SYS DTH1620 Overview
The Attero Tech DTH1620 is multi-channel, low-power (16-channel x 20 watts) Dante/AES67 network amplifier, designed for themed entertainment usage and other specialized audio applications, and optimized for integration into Q-SYS. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- Frequency response @ 1 W into 8 ohm: 20 Hz to 20 kHz
- Signal-to-noise: 97 dB (20 W into 8 ohm)
- Output circuitry: Class D
- Mic/line inputs: Molex 6-pin, +24 V DC
- Speaker outputs: Molex 16-pin
- Headphone/volume control: Molex 6-pin
Technical Specifications:
| Spec | Value |
|---|---|
| Model | DTH1620 |
| Brand | Q-SYS |
| Frequency response @ 1 W into 8 ohm | 20 Hz to 20 kHz |
| Signal-to-noise | 97 dB (20 W into 8 ohm) |
| Output circuitry | Class D |
| Mic/line inputs | Molex 6-pin, +24 V DC |
| Speaker outputs | Molex 16-pin |
| Headphone/volume control | Molex 6-pin |
| Ehternet | RJ-45 with link and activity LED indicators |
| Power Requirements | +24 V DC @ 3 A, all channels 1/8 power +24 V DC @ 17.5 A, all channels full power |
| Cooling | Fan with thermal speed control |
| Dimensions | 9 x 6.7 x 2.0 in (229 x 169 x 51 mm) |
| Weight | 2.4 lbs (1.1 kg) |
Why Buy the Q-SYS DTH1620 from Trianze Tech?
- Genuine Q-SYS product supplied by Trianze Tech with local UAE support
- Pre-sales help designing the Q-SYS system around the DTH1620
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Q-SYS DTH1620: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The Attero Tech DTH1620 is multi-channel, low-power (16-channel x 20 watts) Dante/AES67 network amplifier, designed for themed entertainment usage and other specialized audio applications, and optimized for integration into Q-SYS.
For the Q-SYS DTH1620, Q-SYS lists the following. Output circuitry: Class D; Mic/line inputs: Molex 6-pin, +24 V DC; Speaker outputs: Molex 16-pin; Headphone/volume control: Molex 6-pin.
For the Q-SYS DTH1620, Q-SYS lists the following. Frequency response @ 1 W into 8 ohm: 20 Hz to 20 kHz.
For the Q-SYS DTH1620, Q-SYS lists the following. Power Requirements: +24 V DC @ 3 A, all channels 1/8 power +24 V DC @ 17.5 A, all channels full power.
For the Q-SYS DTH1620, Q-SYS lists the following. Dimensions: 9 x 6.7 x 2.0 in (229 x 169 x 51 mm); Weight: 2.4 lbs (1.1 kg).
Trianze Tech stocks the Q-SYS DTH1620 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
