Panasonic PT-RZ44K: 42,000 Lumen WUXGA Laser DLP Projector (Lens Sold Separately)
Model
:
PT-RZ44K
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Panasonic PT-RZ44K at a Glance
- Brand
- Panasonic
- Model
- PT-RZ44K
- Category
- Multimedia Projectors
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Panasonic PT-RZ44K Overview
The Panasonic PT-RZ44K is a 42,000 lumen WUXGA laser DLP projector (lens sold separately). Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 42,000 lumens of brightness (laser light source rated up to 20,000 hours)
- Resolution: WUXGA (1920 x 1200 pixels)
- Lens: Optional (No lens included with this model)
- Lens shift: +/-55 % vertical, +/-20 % horizontal
- Contrast ratio 25,000: 1(Full On/Full Off, Dynamic Contrast [3])
- Operation noise 49 dB [NORMAL]
Technical Specifications:
| Spec | Value |
|---|---|
| Model | PT-RZ44K |
| Type | Laser dlp projector |
| Projector type | 3-Chip DLP projector |
| Display method | DLP chip x 3, DLP projection system |
| Display Device: Panel size | 24.4 mm (0.96 in) diagonal (16:10 aspect ratio) |
| Display Device: Number of pixels | 2,304,000 (1920 x 1200 pixels) x 3 |
| Light source | Laser diodes (Blue LD, Red LD) |
| Light output | 42,000 lm |
| Light output (ANSI) | 42,000 lm |
| Light output (Center) | 43,600 lm |
| Time until light output declines to 50 %: NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 %: ECO | 24,000 hours [ECO] |
| Time until light output declines to 50 %: QUIET | 26,000 hours [QUIET] |
| Resolution | WUXGA (1920 x 1200 pixels) |
| Contrast Ratio (typ.) | 25,000: 1(Full On/Full Off, Dynamic Contrast [3]) |
| Screen size (diagonal) | 1.78 to 25.40 m (70 to 1000 in) (Depending on attached lens) |
| Center-to-corner zone ratio | 90% |
| Lens | Optional (No lens included with this model) |
| Lens shift: Vertical(from center of screen) | +/-55 % (+68 %, +78 % with ET-D75LE95, +/-48 % with ET-D3LEW201,+/-44 % with ET-D3LEW60/D3LEW300/D3LEW600) (Powered) |
| Lens shift: Horizontal(from center of screen) | +/-20 % (+/-15 % with ET-D3LEW300/D3LEW600/D3LEW201, +/-12 % with ET-D75LE95,0 %, +25 % with ET-D3LEU101) (Powered) |
| Keystone correction range | Vertical: +/-45 degrees |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals: SDI IN | BNC x 1: 12G / SDI input |
| Terminals: HDMI IN | HDMI x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input) |
| Terminals: MULTI PROJECTOR SYNC IN | BNC x 1 |
| Terminals: MULTI PROJECTOR SYNC OUT | BNC x 1 |
| Terminals: SERIAL IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals: REMOTE 1 IN | M3 stereo mini-jack x 1 for wired remote control |
| Terminals: REMOTE 1 OUT | M3 stereo mini-jack x 1 for link control (for wired remote control) |
| Terminals: LAN | RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Terminals: DC OUT | USB Connector Type A x 1 (for power supply, DC 5 V, 2 A) |
| Terminals: USB TYPE A | USB connector Type A x 1 for optional AJ-WM50 Series Wireless Module/USB memory |
| Terminals: SLOT | Open slot for function boards, Intel SDM standard-compatible |
| Protocol versions | IPv4, IPv6 |
| Power supply | Single Phase AC 100 to 240 V, 50/60 Hz |
| Maximum power consumption | Approx.3,110 W |
Why Buy the Panasonic PT-RZ44K from Trianze Tech?
- Genuine Panasonic Laser DLP projector supplied by Trianze Tech with local UAE support
- Pre-sales help choosing the right accessories and installation for the PT-RZ44K
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Panasonic PT-RZ44K: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
For the Panasonic PT-RZ44K, Panasonic lists the following. Light output: 42,000 lm; Light output (ANSI): 42,000 lm; Resolution: WUXGA (1920 x 1200 pixels); Contrast ratio: 25,000: 1(Full On/Full Off, Dynamic Contrast [3]).
For the Panasonic PT-RZ44K, Panasonic lists the following. Lens: Optional (No lens included with this model); Screen size: 1.78 to 25.40 m (70 to 1000 in) (Depending on attached lens); Lens shift vertical: +/-55 % (+68 %, +78 % with ET-D75LE95, +/-48 % with ET-D3LEW201,+/-44 % with ET-D3LEW60/D3LEW300/D3LEW600) (Powered); Keystone: Vertical: +/-45 degrees.
For the Panasonic PT-RZ44K, Panasonic lists the following. SDI IN: BNC x 1: 12G / SDI input; HDMI IN: HDMI x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input); MULTI PROJECTOR SYNC IN: BNC x 1; MULTI PROJECTOR SYNC OUT: BNC x 1; SERIAL IN: D-sub 9-pin (female) x 1 for external control (RS-232C compliant); REMOTE 1 IN: M3 stereo mini-jack x 1 for wired remote control.
For the Panasonic PT-RZ44K, Panasonic lists the following. Time until light output declines to 50 %: NORMAL: 20,000 hours [NORMAL]; Time until light output declines to 50 %: ECO: 24,000 hours [ECO]; Time until light output declines to 50 %: QUIET: 26,000 hours [QUIET]; Operation noise: 49 dB [NORMAL].
For the Panasonic PT-RZ44K, Panasonic lists the following. Dimensions: Approx. 598 x 352 x 780 mm (23 17/32" x 13 27/32" x 30 23/32") (Not including protruding parts); Weight: Approx. 66.5 kg (146.6 lbs); Power supply: Single Phase AC 100 to 240 V, 50/60 Hz; Maximum power consumption: Approx.3,110 W.
Trianze Tech stocks the Panasonic PT-RZ44K in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
