Panasonic PT-RZ34K2: 30,500 Lumen WUXGA Laser DLP Projector (Lens Sold Separately)
Model
:
PT-RZ34K2
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Panasonic PT-RZ34K2 at a Glance
- Brand
- Panasonic
- Model
- PT-RZ34K2
- Category
- Multimedia Projectors
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Panasonic PT-RZ34K2 Overview
The Panasonic PT-RZ34K2 is a 30,500 lumen WUXGA laser DLP projector (lens sold separately). Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 30,500 lumens of brightness (laser light source rated up to 20,000 hours)
- Resolution: WUXGA (1920 x 1200 pixels)
- Lens: Optional (no lens included with this model)
- Lens shift: +/-55 % vertical, +/-20 % horizontal
- Contrast ratio 20,000:1 (Full On/Full Off, Dynamic Contrast [3])
- Operation noise 49 dB [NORMAL]
Technical Specifications:
| Spec | Value |
|---|---|
| Model | PT-RZ34K2 |
| Type | Laser dlp projector |
| Projector type | 3-Chip DLPTMprojector |
| Display method | DLP chip x 3, DLP projection system |
| Display Device: Panel size | 24.4 mm (0.96 in) diagonal (16:10 aspect ratio) |
| Display Device: Number of pixels | 2,304,000 (1920 x 1200 pixels) x 3 |
| Light source | Laser diodes (Blue LD, Red LD) |
| Light output | 30,500 lm |
| Light output (ANSI) | 30,500 lm |
| Light output (Center) | 32,000 lm (Center) |
| Time until light output declines to 50 %: NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 %: ECO | 24,000 hours [ECO] |
| Time until light output declines to 50 %: QUIET | 26,000 hours [QUIET] |
| Resolution | WUXGA (1920 x 1200 pixels) |
| Contrast Ratio (typ.) | 20,000:1 (Full On/Full Off, Dynamic Contrast [3]) |
| Screen size (diagonal) | 1.78 to 25.4 m (70 to 1,000 in), 1.78 to 15.24 m (70 to 600 in) with ET-D75LE8/ET-D3LET80, 3.05 to 15.24 m (120 to 600 in) with ET-D75LE95, 5.08 to 15.24 m (200 to 600 in) with ET-D3LEU100/D3LEU101/ET-D3LEW200/D3LEW201 |
| Center-to-corner zone ratio | 90% |
| Lens | Optional (no lens included with this model) |
| Lens shift: Vertical(from center of screen) | +/-55 % (+78 %, +68 % with ET-D75LE95, +/-48 % with ET-D3LEW200/D3LEW201,+/-44 % with ET-D75LE6/ET-D3LEW60/ET-D3LEW300/ET-D3LEW600) (powered) |
| Lens shift: Horizontal(from center of screen) | +/-20 % (+/-15 % with ET-D75LE6/ET-D3LEW60/ET-D3LEW300/ET-D3LEW600/ET-D3LEW200/D3LEW201,+/-12 % with ET-D75LE95, +25 %, 0 % with ET-D3LEU100/D3LEU101) (powered) |
| Keystone correction range | Vertical: +/-45 degrees |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals: SDI IN | BNC x 1: 3G/HD-SDI input |
| Terminals: HDMI IN | HDMI x 1 (Deep Color, compatible with HDCP 2.2, 4K/60p signal input) |
| Terminals: DVI-D IN | DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP) (Single-link only) |
| Terminals: MULTI SYNC IN/ 3D SYNC 1 IN/OUT (dual purpose) | BNC x 1 |
| Terminals: MULTI SYNC OUT/ 3D SYNC 2 OUT (dual purpose) | BNC x 1 |
| Terminals: SERIAL IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals: SERIAL OUT | D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals: REMOTE 1 IN | M3 stereo mini-jack x 1 for wired remote control |
| Terminals: REMOTE 1 OUT | M3 stereo mini-jack x 1 for link control |
| Terminals: REMOTE 2 IN | D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals: DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connection (HDBaseT compliant), 100Base-TX, compatible with Art-Net, PJLink (Class 2), Deep Color, HDCP 2.2, 4K/60p signal input |
| Terminals: LAN | RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Terminals: DC OUT | USB Type A x 2 (for power supply, DC 5 V total of 2 A) |
| Terminals: USB TYPE A | USB connector (Type A) x 1 for optional Wireless Module (AJ-WM50 Series)/USB Memory Stick |
Why Buy the Panasonic PT-RZ34K2 from Trianze Tech?
- Genuine Panasonic Laser DLP projector supplied by Trianze Tech with local UAE support
- Pre-sales help choosing the right accessories and installation for the PT-RZ34K2
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Panasonic PT-RZ34K2: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
For the Panasonic PT-RZ34K2, Panasonic lists the following. Light output: 30,500 lm; Light output (ANSI): 30,500 lm; Resolution: WUXGA (1920 x 1200 pixels); Contrast ratio: 20,000:1 (Full On/Full Off, Dynamic Contrast [3]).
For the Panasonic PT-RZ34K2, Panasonic lists the following. Lens: Optional (no lens included with this model); Screen size: 1.78 to 25.4 m (70 to 1,000 in), 1.78 to 15.24 m (70 to 600 in) with ET-D75LE8/ET-D3LET80, 3.05 to 15.24 m (120 to 600 in) with ET-D75LE95, 5.08 to 15.24 m; Lens shift vertical: +/-55 % (+78 %, +68 % with ET-D75LE95, +/-48 % with ET-D3LEW200/D3LEW201,+/-44 % with ET-D75LE6/ET-D3LEW60/ET-D3LEW300/ET-D3LEW600) (powered); Keystone: Vertical: +/-45 degrees.
For the Panasonic PT-RZ34K2, Panasonic lists the following. SDI IN: BNC x 1: 3G/HD-SDI input; HDMI IN: HDMI x 1 (Deep Color, compatible with HDCP 2.2, 4K/60p signal input); DVI-D IN: DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP) (Single-link only); MULTI SYNC IN/ 3D SYNC 1 IN/OUT (dual purpose): BNC x 1; MULTI SYNC OUT/ 3D SYNC 2 OUT (dual purpose): BNC x 1; SERIAL IN: D-sub 9-pin (female) x 1 for external control (RS-232C compliant).
For the Panasonic PT-RZ34K2, Panasonic lists the following. Time until light output declines to 50 %: NORMAL: 20,000 hours [NORMAL]; Time until light output declines to 50 %: ECO: 24,000 hours [ECO]; Time until light output declines to 50 %: QUIET: 26,000 hours [QUIET]; Operation noise: 49 dB [NORMAL].
For the Panasonic PT-RZ34K2, Panasonic lists the following. Dimensions: Approx. 598 x 353 x 780 mm (23 17/32" x 13 29/32" x 30 23/32") (not including protruding parts); Weight: Approx. 68.6 kg (151.2 lbs); Power supply: AC 200 V, 240 V (Light output will decrease when using the projector with AC 100 V to AC 120 V); Maximum power consumption: 2,450 W (2,470 VA).
Trianze Tech stocks the Panasonic PT-RZ34K2 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
