Panasonic PT-RQ50K: 50,000 Lumen 4K Laser DLP Projector (Lens Sold Separately)
Model
:
PT-RQ50K
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Panasonic PT-RQ50K at a Glance
- Brand
- Panasonic
- Model
- PT-RQ50K
- Category
- Multimedia Projectors
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Panasonic PT-RQ50K Overview
The Panasonic PT-RQ50K is a 50,000 lumen 4K laser DLP projector (lens sold separately). Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 50,000 lumens of brightness (laser light source rated up to 20,000 hours)
- Resolution: Native 4K (4096 x 2160 pixels)
- Lens: Optional (no lens included with this model)
- Lens shift: +/-45 % vertical, +/-16 % horizontal
- Contrast ratio 25,000:1 (Full On/Full Off, Dynamic Contrast [3])
- Operation noise 52 dB [NORMAL]
Technical Specifications:
| Spec | Value |
|---|---|
| Model | PT-RQ50K |
| Type | Laser dlp projector |
| Projector type | 3-Chip DLPTMprojector |
| Display method | DLP chip x 3, DLP projection system |
| Display Device: Panel size | 35.1 mm (1.38 in) diagonal (17:9 aspect ratio) |
| Display Device: Number of pixels | 8,847,360 (4096 x 2160 pixels) x 3 |
| Light source | Laser diodes (Blue LD, Red LD) |
| Light output | 50,000 lm |
| Light output (ANSI) | 50,000 lm |
| Light output (Center) | 51,000 lm (Center) |
| Time until light output declines to 50 %: NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 %: ECO | 24,000 hours [ECO] |
| Resolution | Native 4K (4096 x 2160 pixels) |
| Contrast Ratio (typ.) | 25,000:1 (Full On/Full Off, Dynamic Contrast [3]) |
| Screen size (diagonal) | 2.54 to 38.1 m (100 to 1,500 in) with new optional lens for PT-RQ50K, 17:9 aspect ratio |
| Center-to-corner zone ratio | 90% |
| Lens | Optional (no lens included with this model) |
| Lens shift: Vertical(from center of screen) | +/-45 % (+/-25 % with ET-D3QT600, +/-30 % with ET-D3QT700/ET-D3QT800, +/-40 % with ET-D3QW300) (powered) |
| Lens shift: Horizontal(from center of screen) | +/-16 % (+/-8 % with ET-D3QT600, +/-10 % with ET-D3QT700/ET-D3QT800, +/-14 % with ET-D3QW300) (powered) |
| Keystone correction range | Vertical: +/-40 degrees (+/-28 degrees with ET-D3QW300), Horizontal: +/-40 degrees (+/-15 degrees with ET-D3QW300) |
| Installation | Horizontal/vertical, free 360-degree installation |
| Terminals: MULTI PROJECTOR SYNC IN | BNC x 1 |
| Terminals: MULTI PROJECTOR SYNC OUT | BNC x 1 |
| Terminals: SERIAL IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals: SERIAL OUT | D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals: REMOTE 1 IN | M3 stereo mini-jack x 1 for wired remote control |
| Terminals: REMOTE 1 OUT | M3 stereo mini-jack x 1 for link control |
| Terminals: REMOTE 2 IN | D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals: DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connections (HDBaseT compliant), PJLink (Class 2) compatible, 100Base-TX, Art-Net compatible, HDCP 2.2 compatible, Deep Color compatible |
| Terminals: LAN | RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Terminals: DC OUT | USB Connector (Type A) x 2 for power supply only (DC 5 V, total of 2 A) |
| Terminals: USB TYPE A | USB connector (Type A) x 1 for optional Wireless Module (AJ-WM50 Series) / USB Memory Stick |
| Power supply | AC 200 to 240 V, 50/60 Hz; AC 100 to 120 V, 50/60 Hz |
| Maximum power consumption | 4,100 W (AC 100 to 120 V: 1,100 W) |
| On-mode power consumption(Operating mode): Normal | 3,970 W |
| On-mode power consumption(Operating mode): Eco | 3,110 W |
Why Buy the Panasonic PT-RQ50K from Trianze Tech?
- Genuine Panasonic Laser DLP projector supplied by Trianze Tech with local UAE support
- Pre-sales help choosing the right accessories and installation for the PT-RQ50K
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Panasonic PT-RQ50K: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
For the Panasonic PT-RQ50K, Panasonic lists the following. Light output: 50,000 lm; Light output (ANSI): 50,000 lm; Resolution: Native 4K (4096 x 2160 pixels); Contrast ratio: 25,000:1 (Full On/Full Off, Dynamic Contrast [3]).
For the Panasonic PT-RQ50K, Panasonic lists the following. Lens: Optional (no lens included with this model); Screen size: 2.54 to 38.1 m (100 to 1,500 in) with new optional lens for PT-RQ50K, 17:9 aspect ratio; Lens shift vertical: +/-45 % (+/-25 % with ET-D3QT600, +/-30 % with ET-D3QT700/ET-D3QT800, +/-40 % with ET-D3QW300) (powered); Keystone: Vertical: +/-40 degrees (+/-28 degrees with ET-D3QW300), Horizontal: +/-40 degrees (+/-15 degrees with ET-D3QW300).
For the Panasonic PT-RQ50K, Panasonic lists the following. MULTI PROJECTOR SYNC IN: BNC x 1; MULTI PROJECTOR SYNC OUT: BNC x 1; SERIAL IN: D-sub 9-pin (female) x 1 for external control (RS-232C compliant); SERIAL OUT: D-sub 9-pin (male) x 1 for link control (RS-232C compliant); REMOTE 1 IN: M3 stereo mini-jack x 1 for wired remote control; REMOTE 1 OUT: M3 stereo mini-jack x 1 for link control.
For the Panasonic PT-RQ50K, Panasonic lists the following. Time until light output declines to 50 %: NORMAL: 20,000 hours [NORMAL]; Time until light output declines to 50 %: ECO: 24,000 hours [ECO]; Operation noise: 52 dB [NORMAL].
For the Panasonic PT-RQ50K, Panasonic lists the following. Dimensions: Approx. 720 x 445 x 1,070 mm (28 11/32" x 17 17/32" x 42 1/8") (excluding handle, adjuster feet, and other protruding parts); Weight: Approx. 126 kg (278 lbs) (without lens); Power supply: AC 200 to 240 V, 50/60 Hz; AC 100 to 120 V, 50/60 Hz; Maximum power consumption: 4,100 W (AC 100 to 120 V: 1,100 W).
Trianze Tech stocks the Panasonic PT-RQ50K in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
