Panasonic PT-MZ11KL: 11,000 Lumen WUXGA Laser LCD Projector (Lens Sold Separately)
Model
:
PT-MZ11KL
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Panasonic PT-MZ11KL at a Glance
- Brand
- Panasonic
- Model
- PT-MZ11KL
- Category
- Multimedia Projectors
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Panasonic PT-MZ11KL Overview
The Panasonic PT-MZ11KL is a 11,000 lumen WUXGA laser LCD projector (lens sold separately). Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- 11,000 lumens of brightness (laser light source rated up to 20,000 hours)
- Resolution: WUXGA (1920 x 1200 pixels)
- Lens: Optional (no lens included with this model)
- Lens shift: +/-60 % vertical, +/-20 % (+/-19 % with ET-EMW200) (powered) horizontal
- Contrast ratio 3,000,000:1 (Full On/Full Off)
- Operation noise 35 dB [NORMAL]
Technical Specifications:
| Spec | Value |
|---|---|
| Model | PT-MZ11KL |
| Type | Laser lcd projector |
| Projector type | LCD projectors |
| Display method | Transparent LCD panel (x 3, R/G/B) |
| Display Device: Panel size | 25.4 mm (1.0 in) diagonal (16:10 aspect ratio) |
| Display Device: Drive method | Active matrix method |
| Display Device: Number of pixels | 2,304,000 (1920 x 1200 pixels) |
| Light source | Laser diode |
| Light output | 11,000 lm |
| Light output (ANSI) | 11,000 lm |
| Time until light output declines to 50 %: NORMAL | 20,000 hours [NORMAL] |
| Time until light output declines to 50 %: QUIET | 20,000 hours [QUIET] |
| Resolution | WUXGA (1920 x 1200 pixels) |
| Contrast Ratio (typ.) | 3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC]and [DYNAMIC CONTRAST] set to [3].) |
| Screen size (diagonal) | 2.03 to 15.24 m (80 to 600 in), 2.54 to 10.16 m (100 to 400 in) with ET-EMU100,2.03 to 12.70 m (80 to 500 in) with ET-EMT800, 16:10 aspect ratio |
| Center-to-corner zone ratio | 85% |
| Lens | Optional (no lens included with this model) |
| Lens shift: Vertical(from center of screen) | +/-60 % (+50 %, -20 % with ET-EMU100, +/-40 % with ET-EMW200, +/-50 % with ET-EMW300) (powered) |
| Lens shift: Horizontal(from center of screen) | +/-20 % (+/-19 % with ET-EMW200) (powered) |
| Keystone correction range | Vertical: +/-45 degrees (+/-5 degrees with ET-EMU100, +/-14 degrees with ET-EMW200/ET-EMW300, +/-22 degrees with ET-EMW400/ET-EMW500),Horizontal: +/-40 degrees |
| Installation | Ceiling/oor, front/rear, free 360-degree installation |
| Terminals: SDI IN | BNC x 1: 3G/HD-SDI input |
| Terminals: HDMI IN | HDMI 19-pin x 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input), CEC supported |
| Terminals: SERIAL/MULTI-PROJECTOR SYNC IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals: SERIAL/MULTI-PROJECTOR SYNC OUT | D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals: REMOTE 1 IN | D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals: REMOTE 2 IN | M3 x 1 for wired remote control |
| Terminals: REMOTE 2 OUT | M3 x 1 for link control (for wired remote control) |
| Terminals: DIGITAL LINK IN / LAN | RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT compliant), 100Base-TX (Compatible with PJLink [Class 2], Art-Net, HDCP 2.3, Deep Color, 4K/60p signal input) |
| Terminals: LAN | RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink [Class 2], Art-Net) |
| Terminals: DC OUT | USB connector (Type A) x 1 for power supply (Output: 5 V / 2 A) |
| Terminals: USB TYPE A | USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module, for USB memory |
| Power supply | AC 100 to 240 V, 50/60 Hz |
| Maximum power consumption | 615 W (6.3 to 2.7 A) (630 VA) |
| On-mode power consumption(Operating mode): Normal | [NORMAL]540 W (AC 100 to 120 V),520 W (AC 200 to 240 V) |
| On-mode power consumption(Operating mode): Quiet | [QUIET]360 W (AC 100 to 120 V),340 W (AC 200 to 240 V) |
Why Buy the Panasonic PT-MZ11KL from Trianze Tech?
- Genuine Panasonic Laser LCD projector supplied by Trianze Tech with local UAE support
- Pre-sales help choosing the right accessories and installation for the PT-MZ11KL
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for meeting rooms, classrooms and venues
What's Included and Support
Frequently asked
Panasonic PT-MZ11KL: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
For the Panasonic PT-MZ11KL, Panasonic lists the following. Light output: 11,000 lm; Light output (ANSI): 11,000 lm; Resolution: WUXGA (1920 x 1200 pixels); Contrast ratio: 3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC]and [DYNAMIC CONTRAST] set to [3].).
For the Panasonic PT-MZ11KL, Panasonic lists the following. Lens: Optional (no lens included with this model); Screen size: 2.03 to 15.24 m (80 to 600 in), 2.54 to 10.16 m (100 to 400 in) with ET-EMU100,2.03 to 12.70 m (80 to 500 in) with ET-EMT800, 16:10 aspect ratio; Lens shift vertical: +/-60 % (+50 %, -20 % with ET-EMU100, +/-40 % with ET-EMW200, +/-50 % with ET-EMW300) (powered); Keystone: Vertical: +/-45 degrees (+/-5 degrees with ET-EMU100, +/-14 degrees with ET-EMW200/ET-EMW300, +/-22 degrees with ET-EMW400/ET-EMW500),Horizontal: +/-40 degrees.
For the Panasonic PT-MZ11KL, Panasonic lists the following. SDI IN: BNC x 1: 3G/HD-SDI input; HDMI IN: HDMI 19-pin x 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input), CEC supported; SERIAL/MULTI-PROJECTOR SYNC IN: D-sub 9-pin (female) x 1 for external control (RS-232C compliant); SERIAL/MULTI-PROJECTOR SYNC OUT: D-sub 9-pin (male) x 1 for link control (RS-232C compliant); REMOTE 1 IN: D-sub 9-pin (female) x 1 for external control (parallel); REMOTE 2 IN: M3 x 1 for wired remote control.
For the Panasonic PT-MZ11KL, Panasonic lists the following. Time until light output declines to 50 %: NORMAL: 20,000 hours [NORMAL]; Time until light output declines to 50 %: QUIET: 20,000 hours [QUIET]; Operation noise: 35 dB [NORMAL].
For the Panasonic PT-MZ11KL, Panasonic lists the following. Dimensions: Approx. 650 x 185 x 440 mm (25 19/32" x 7 9/32" x 17 5/16") (excluding feet and protrusions),650 x 211 x 440 mm (25 19/32" x 8 5/16" x 17 5/16"); Weight: Approx. 22.5 kg (49.6 lbs); Power supply: AC 100 to 240 V, 50/60 Hz; Maximum power consumption: 615 W (6.3 to 2.7 A) (630 VA).
Trianze Tech stocks the Panasonic PT-MZ11KL in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
