Bose ArenaMatch AMWG2060: AM20 60 Degree Horizontal Waveguide Accessory | 808667-3610
The Bose ArenaMatch AMWG2060 is a genuine Bose Professional accessory waveguide that sets the horizontal coverage of an ArenaMatch AM20 DeltaQ array loudspeaker module to 60 degrees, distributed in Dubai, Abu Dhabi and across the UAE and GCC by Trianze Tech for outdoor and installed sound projects.
Key Features
- Swaps onto the AM20 module to change horizontal dispersion to 60 degrees while keeping the module's 20 degree vertical pattern
- Calibrated specifically for the AM20 DeltaQ array loudspeaker, not interchangeable with AM10 or AM40 waveguides
- Lets integrators build lighter, faster to install arrays by changing coverage without swapping the whole loudspeaker
- IP55 rated for direct exposure outdoor use alongside the AM20 module it pairs with
Technical Specifications
| Compatible Module | Bose ArenaMatch AM20 DeltaQ array loudspeaker |
| Coverage Pattern (AM20/60) | 60 degrees horizontal x 20 degrees vertical |
| Sensitivity (1W/1m) | 94 dB LF / 106 dB HF / 99 dB passive |
| Maximum SPL | 122 dB LF / 128 dB HF / 128 dB passive |
| AM20 Driver Complement | Six Bose EMB2S compression drivers and one 14 inch neodymium woofer |
| Power Handling | Up to 750W RMS bi-amplified |
| Frequency Response | 55 Hz to 18 kHz |
| Impedance | 8 ohm passive, 8 ohm plus 8 ohm bi-amp |
| Environmental Rating | IP55 |
| Part Number | 808667-3610 |
Why Buy the Bose ArenaMatch AMWG2060 from Trianze Tech?
- Genuine Bose Professional accessory sourced and supported locally in the UAE
- Fast delivery and installation support across Dubai, Abu Dhabi and the GCC
- Dedicated commercial audio design support from Trianze Tech for ArenaMatch deployments
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Bose AMWG2060 sets the ArenaMatch AM20 DeltaQ array module to a 60 degree horizontal by 20 degree vertical coverage pattern, calibrated specifically for the AM20 module.
No. The AMWG2060 is engineered exclusively for the Bose ArenaMatch AM20 DeltaQ array loudspeaker and is not compatible with AM10 or AM40 modules, which use their own dedicated waveguide part numbers.
Yes. The AMWG2060 carries an IP55 environmental rating, matching the outdoor exposure rating of the AM20 module it attaches to, making it suitable for direct outdoor installation.
The AM20 module supports up to 750W RMS bi-amplified power handling with the AMWG2060 waveguide fitted, with a frequency response of 55 Hz to 18 kHz and maximum SPL of up to 128 dB.
Yes. The AMWG2060 is designed as a field swappable waveguide insert, letting integrators change the AM20 module's horizontal coverage pattern to 60 degrees without removing or replacing the loudspeaker itself.
