Bose ArenaMatch AMWG1010: AM10 100 Degree Horizontal Waveguide Accessory | 808650-8510
The Bose ArenaMatch AMWG1010 is a genuine Bose Professional accessory waveguide that sets the horizontal coverage of an ArenaMatch AM10 DeltaQ array loudspeaker module to 100 degrees, distributed in Dubai, Abu Dhabi and across the UAE and GCC by Trianze Tech.
Key Features
- Swaps onto the AM10 module to widen horizontal dispersion to 100 degrees while keeping the module's 10 degree vertical pattern
- Calibrated specifically for the AM10 DeltaQ array loudspeaker, not interchangeable with AM20 or AM40 waveguides
- Lets integrators cover wide seating areas or plazas with fewer array modules
- IP55 rated for direct exposure outdoor use alongside the AM10 module it pairs with
Technical Specifications
| Compatible Module | Bose ArenaMatch AM10 DeltaQ array loudspeaker |
| Coverage Pattern (AM10/100) | 100 degrees horizontal x 10 degrees vertical |
| Maximum SPL | 122 dB LF / 127 dB HF |
| AM10 Driver Complement | One 14 inch neodymium woofer and six Bose EMB2S titanium diaphragm compression drivers |
| Technology | Bose DeltaQ array technology for precise audience coverage matching |
| Environmental Rating | IP55 |
| Part Number | 808650-8510 |
Why Buy the Bose ArenaMatch AMWG1010 from Trianze Tech?
- Genuine Bose Professional accessory sourced and supported locally in the UAE
- Fast delivery and installation support across Dubai, Abu Dhabi and the GCC
- Dedicated commercial audio design support from Trianze Tech for ArenaMatch deployments
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The AMWG1010 sets the ArenaMatch AM10 DeltaQ array module to a 100 degree horizontal by 10 degree vertical coverage pattern.
No. The AMWG1010 is engineered exclusively for the Bose ArenaMatch AM10 DeltaQ array loudspeaker and is not compatible with AM20 or AM40 modules, which use their own dedicated waveguide part numbers.
Yes. The AMWG1010 carries an IP55 environmental rating, matching the outdoor exposure rating of the AM10 module it attaches to.
The AM10 module uses one 14 inch neodymium woofer and six Bose EMB2S titanium diaphragm compression drivers, reaching a maximum SPL of 122 dB LF and 127 dB HF with the AMWG1010 waveguide fitted.
Yes. The AMWG1010 is a field swappable waveguide insert, letting integrators widen the AM10 module's horizontal coverage to 100 degrees without removing or replacing the loudspeaker itself.
Trianze Tech stocks the Bose AMWG1010 waveguide in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
