Bose L1 Pro16 Portable Line Array System: 16-Driver PA with Integrated Mixer, Bluetooth and L1 Mix App | 840920-4100
The Bose L1 Pro16 is a genuine Bose Professional portable line array PA system built for medium to large venues, distributed in Dubai, Abu Dhabi and across the UAE and GCC by Trianze Tech.
Its J-shaped array of 16 articulated 2 inch neodymium drivers delivers 180 degree horizontal coverage with tight vertical control on top and wide dispersion at the bottom, so audiences are covered evenly whether the system is on the floor or an elevated stage, even off to the extreme sides. An integrated RaceTrack subwoofer packs powerful bass into a slim 10 x 18 inch driver that rivals a conventional 15 inch woofer without the bulk.
Key Features
- 16x articulated 2 inch neodymium mid-high drivers plus an 18x10 inch RaceTrack subwoofer
- Built-in mixer with 2 combo XLR / quarter inch phantom-powered inputs, quarter inch and 3.5mm aux inputs
- Bluetooth streaming plus a dedicated ToneMatch port for an optional Bose T4S or T8S mixer
- Full wireless mixer control from a phone or tablet via the free L1 Mix app
Technical Specifications
| Part Number | 840920-4100 |
| Configuration | 16x 2 inch mid-high drivers, 1x 18x10 inch RaceTrack subwoofer |
| Amplifier Power | 250W array, 1000W subwoofer |
| Frequency Response | 42Hz to 20kHz |
| Maximum SPL | 118dB continuous, 124dB peak |
| Coverage | 180 degrees horizontal |
| Dimensions (Extended) | 79.2 x 14.0 x 18.0 in (2011 x 355 x 456mm) |
| Dimensions (Collapsed) | 67.0 x 14.0 x 18.0 in (1704 x 355 x 456mm) |
| Net Weight | Approx. 54.8 lb (24.9kg) |
| Inputs | 2x combo XLR / quarter inch, quarter inch and 3.5mm aux, Bluetooth, ToneMatch |
| Control | L1 Mix app (iOS and Android) |
Why Buy the Bose L1 Pro16 from Trianze Tech?
- Genuine Bose Professional system sourced and supported locally in the UAE
- Fast delivery and setup support for events across Dubai, Abu Dhabi and the GCC
- Dedicated pro audio and live sound support from Trianze Tech
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The L1 Pro16 uses 16 articulated 2 inch neodymium mid-high drivers in a J-shaped array plus an integrated 18x10 inch RaceTrack subwoofer, delivering 180 degree horizontal coverage with a 42Hz to 20kHz frequency response and up to 124dB peak SPL.
Yes, the built-in mixer has 2 combo XLR / quarter inch phantom-powered inputs plus quarter inch and 3.5mm aux inputs, so a microphone and an instrument or playback device can run simultaneously, with Bluetooth available for wireless streaming.
Yes, the free L1 Mix app gives full wireless control of the built-in mixer from a phone or tablet, letting you walk the room and adjust volume, tone and reverb per channel in real time while the LED encoders on the unit stay in sync.
The complete L1 Pro16 system weighs approximately 54.8 lb (24.9kg) and collapses from an extended height of 79.2 inches to a compact 67.0 inches for transport, with the RaceTrack subwoofer's slim 10x18 inch driver keeping the packed footprint small.
Yes, the dedicated ToneMatch port carries both power and digital audio to an optional Bose T4S or T8S mixer over a single cable, expanding the L1 Pro16 with additional channels for larger bands or productions.
Trianze Tech stocks the Bose L1 Pro16 Portable Line Array System in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
