Bose ControlSpace ESP-880A Processor
Model
:
812862-4110
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Bose ControlSpace ESP-880A Processor
The Bose ControlSpace ESP-880A is a genuine Bose Professional open architecture engineered sound processor, distributed in Dubai, Abu Dhabi and across the UAE and GCC by Trianze Tech for installed sound and conferencing applications.
Key Features
- Open architecture floating point DSP with 3.6 GIPS / 2.7 GFLOPS processing power
- 8x8 balanced analog audio I/O at 48kHz/24-bit with 115dB dynamic range
- 8-channel Bose AmpLink digital output for direct connection to Bose amplifiers over Cat5
- Onboard RS-232, 5 control inputs and 5 control outputs for automation integration
- Compatible with Crestron, AMX and Bose ControlCenter zone controllers
- Configured and monitored live using Bose ControlSpace Designer software
Technical Specifications
| Part Number | 812862-4110 |
| Format | 1U rackmount, 1.7 x 19.0 x 8.5 in |
| Weight | 5.7 lb (2.6 kg) |
| Analog I/O | 8 balanced inputs, 8 balanced outputs |
| Sample Rate / Bit Depth | 48 kHz / 24-bit |
| Dynamic Range | 115 dB |
| Latency | 860 microseconds analog to analog |
| Processing | 3.6 GIPS / 2.7 GFLOPS floating point DSP, Arm 456MHz CPU |
| Digital Output | 8-channel Bose AmpLink over Cat5 |
| Control I/O | RS-232, 5 control inputs, 5 control outputs |
| Third Party Control | Crestron, AMX compatible |
Why Buy the Bose ControlSpace ESP-880A from Trianze Tech?
- Genuine Bose Professional gear sourced and supported locally in the UAE
- Fast delivery and installation support across Dubai, Abu Dhabi and the GCC
- Dedicated commercial audio system design and integration support from Trianze Tech
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Bose ControlSpace ESP-880A provides 8 balanced analog inputs and 8 balanced analog outputs at 48kHz/24-bit resolution, plus an 8-channel Bose AmpLink digital output for direct connection to compatible Bose amplifiers.
Yes. The ESP-880A includes onboard RS-232 plus 5 control inputs and 5 control outputs, allowing direct integration with industry standard control systems including Crestron and AMX, alongside Bose ControlCenter zone controllers.
The ESP-880A occupies a single 1U rack space at 1.7 x 19.0 x 8.5 inches and weighs 5.7 lb (2.6 kg).
The ESP-880A is configured, monitored and tuned using Bose ControlSpace Designer software, which includes automatic mic mixers, feedback suppressors, room combiners, EQs and Bose loudspeaker libraries, all programmable and live tunable on site.
The ESP-880A delivers an analog to analog latency of just 860 microseconds, powered by a 3.6 GIPS / 2.7 GFLOPS floating point DSP alongside an Arm 456MHz CPU.
Trianze Tech stocks the Bose ControlSpace ESP-880A Processor in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
