Audio-Technica BP28L: Microphone
The Audio-Technica BP28L combines a large-diaphragm condenser element with a 28 mm diameter shotgun body for exceptional low-noise performance. Supplied by Trianze Tech across Dubai, Abu Dhabi, the UAE and the GCC.
Key Features:
- Designed for use in broadcasting, film/TV production, and theater sound reinforcement applications
- Overall length of 22.4 inch with an extremely narrow, highly directional pickup pattern
- The custom 28 mm diameter shotgun body houses a large-diaphragm condenser element for exceptional low-noise performance
- Transformer-coupled output provides smooth sonic character
- Extremely high sensitivity (-23 dBV), wide dynamic range (135 dB), and high-SPL capability (138 dB)
- Flat frequency response for accurate sound reproduction
- Rugged housing made of lightweight, structural-grade aluminum alloy
Technical Specifications:
| Spec | Value |
|---|---|
| Brand | Audio-Technica |
| Model | BP28L |
| Product Type | Shotgun Mics |
| Polar Pattern | Line + gradient |
| Frequency Response | 20 to 20,000 Hz |
| Low Frequency Roll Off | 80 Hz, 18 dB/octave |
| Open Circuit Sensitivity | -23 dB (70.8 mV) (0 dB=1 V/Pa, 1 kHz) |
| Impedance | 250 ohms |
| Maximum Input Sound Level | 138 dB SPL (1 kHz at 1% THD) 148 dB SPL (When pad is on.) |
| Noise | 3 dB SPL (A-weighted) |
| Dynamic Range | 135 dB (1 kHz at Max SPL) |
| Signal-to-Noise Ratio | 91 dB (1 kHz at 1 Pa, A-weighted) |
| Phantom Power Requirements | 11- 52 V DC, 3.4 mA |
| Switches | Low cut: on/off Pad: on/off |
| Low cut | on/off |
| Pad | on/off |
| Weight | 313 g (11 oz) |
| Dimensions | 567.9 mm (22.4 inch) long, 28.0 mm (1.1 inch) maximum body diameter |
| Output Connector | Integral 3-pin XLR-M type |
| Audio-Technica Case Style | SG7 |
Why Buy the Audio-Technica BP28L Microphone from Trianze Tech?
- Genuine Audio-Technica product sourced through authorized channels with local UAE support
- Pre-sales help matching the BP28L to your microphones, mixers and installation
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Procurement-ready quotations for venues, broadcasters, schools and corporate projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Audio-Technica BP28L uses a Line + gradient polar pattern. Overall length of 22.4 inch with an extremely narrow, highly directional pickup pattern.
The Audio-Technica BP28L has a frequency response of 20 to 20,000 Hz, with a low frequency roll-off of 80 Hz, 18 dB/octave.
The Audio-Technica BP28L has an open circuit sensitivity of -23 dB (70.8 mV) (0 dB=1 V/Pa, 1 kHz), and a maximum input sound level of 138 dB SPL (1 kHz at 1% THD) 148 dB SPL (When pad is on.). Trianze Tech can confirm figures for your application.
Published specifications list the power requirement of the Audio-Technica BP28L as 11- 52 V DC, 3.4 mA.
The Audio-Technica BP28L has Integral 3-pin XLR-M type as its connector.
