Audio-Technica ATW-3211DE2: 3000 Series Wireless Bodypack System
Brand
:Audio-Technica
Model
:
ATW-3211DE2
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Audio-Technica ATW-3211DE2: 3000 Series Wireless Bodypack System
Providing easy setup, versatile operation and rock-solid, richly detailed high-fidelity sound, Audio-Technica's fourth-generation 3000 Series wireless systems give users the power and flexibility to operate within the congested UHF spectrum. Supplied by Trianze Tech across Dubai, Abu Dhabi, the UAE and the GCC.
Key Features:
- Extremely wide 60 MHz UHF tuning bandwidth for maximum versatility in an increasingly congested RF environment; available in four frequency bands: DE2 (470 to 530 MHz), EE1 (530 to 590 MHz), EF1 (590 to 650 MHz) and FG1 (650 to 700 MHz).
- Unique multifunction button on the body-pack transmitter can be used to switch to a backup frequency (on both transmitter and receiver) should interference be encountered
- True Diversity operation reduces dropouts
- Auto Squelch feature automatically adjusts squelch setting to maximize range while minimizing potential interference
- Frequency scan and IR sync functionality for ease of setup
- Dual-mode receiver display can switch between standard view or a performance view that highlights key metering
- Transmitter and receiver include OLED screens for optimal readout of key settings and alerts
Technical Specifications:
| Spec | Value |
|---|---|
| Brand | Audio-Technica |
| Model | ATW-3211DE2 |
| Product Type | UHF Wireless Combo Mic Systems |
| Minimum Frequency Step | 25 kHz |
| Modulation Mode | FM |
| Atw-T3201 | 38 kHz (THD:10%) |
| Atw-T3202 | 36 kHz (THD:10%) |
| Simultaneous Use | 40 Channels per band* |
| Total Harmonic Distortion | <1.0% (at 1 kHz, 17.5 kHz deviation) |
| Operating Temperature Range | -5 degreesC to +45 degreesC |
| Receiving System | True Diversity |
| Sensitivity | 20 dBuV at 60 dBA S/N ratio (50? termination) |
| XLR / Balanced | +14 dBV |
| 6.3 mm ("") / Unbalanced | +8 dBV |
| Antenna Input | BNC-type, 50 ? |
| Power Output | 12 V DC, 160 mA (combined) |
| Power Supply | 100 to 240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply |
| Dimensions | 210.0 mm x 191.0 mm x 43.4 mm (W x D x H) |
| Weight | 1100 g, without accessories |
| RF Power Output | High: 30 mW, Low: 10 mW (switchable), at 50 ? |
| Spurious Emissions | Following Federal and National Regulations |
Why Buy the Audio-Technica ATW-3211DE2 3000 Series Wireless Bodypack System from Trianze Tech?
- Genuine Audio-Technica product sourced through authorized channels with local UAE support
- Pre-sales help matching the ATW-3211DE2 to your microphones, mixers and installation
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Procurement-ready quotations for venues, broadcasters, schools and corporate projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
Published specifications list the power requirement of the Audio-Technica ATW-3211DE2 as 100 to 240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply.
The RF power output of the Audio-Technica ATW-3211DE2 is High: 30 mW, Low: 10 mW (switchable), at 50 ?. Check local wireless regulation before use in the UAE.
Published specifications list the dimensions of the Audio-Technica ATW-3211DE2 as 210.0 mm x 191.0 mm x 43.4 mm (W x D x H), and the weight of the Audio-Technica ATW-3211DE2 as 1100 g, without accessories.
Extremely wide 60 MHz UHF tuning bandwidth for maximum versatility in an increasingly congested RF environment; available in four frequency bands: DE2 (470 to 530 MHz), EE1 (530 to 590 MHz), EF1 (590. Unique multifunction button on the body-pack transmitter can be used to switch to a backup frequency (on both transmitter and receiver) should interference be encountered.
True Diversity operation reduces dropouts. Auto Squelch feature automatically adjusts squelch setting to maximize range while minimizing potential interference.
Trianze Tech stocks the Audio-Technica ATW-3211DE2 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
