Audio-Technica ATW-1322: Dual Channel Dynamic Handheld Microphone Rack Mount Wireless System
Brand
:Audio-Technica
Model
:
ATW-1322
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Audio-Technica ATW-1322: Dual Channel Dynamic Handheld Microphone Rack Mount Wireless System
The Audio-Technica ATW-1322 Dual Channel Dynamic Handheld Microphone Rack Mount Wireless System delivers superior sound quality and operational reliability. Designed to provide outstanding performance within the 2.4 GHz range, free from TV bands interference, this system is perfect for professional musicians, live sound engineers, and presenters who demand unparalleled audio clarity and flexibility. Supplied by Trianze Tech across Dubai, Abu Dhabi, the UAE and the GCC.
Key Features:
- Digital 24-bit/48 kHz wireless operation for ultimate sound quality and dependable performance
- Operates in the 2.4 GHz range, completely free from TV interference
- Receiver units can be docked in the chassis or mounted remotely (up to 328 feet away) via Ethernet cable for added versatility
- Up to five chassis (ten receiver units) can be linked and used simultaneously
- Each receiver unit can be paired with up to 10 transmitters, allowing users to instantly switch between different transmitter configurations
- Chassis' System ID Display shows RF signal level, system ID, transmitter battery level, and system link status
- Automatic frequency selection for seamless, interference-free operation
Technical Specifications:
| Spec | Value |
|---|---|
| Brand | Audio-Technica |
| Model | ATW-1322 |
| Product Type | Digital Handheld Wireless Mics |
| Operating Frequencies | 2.4 GHz ISM band |
| Dynamic Range | >109 dB (A-weighted), typical |
| Total Harmonic Distortion | <0.05% typical |
| Operating Range | 60 m (200') (Open range environment with no interfering signals) |
| Operating Temperature Range | 0 degrees C to +40 degrees C (32 degrees F to 104 degrees F) (Battery performance may be reduced at very low temperatures) |
| Frequency Response | 20 Hz to 20 kHz (Depending on microphone type) |
| RF Power Output | 10 mW |
| Spurious Emissions | Following federal and national regulations |
| Input Connections | Four-pin Locking Connector (Pin 1: GND, Pin 2: INST INPUT, Pin 3: MIC INPUT, Pin 4: DC BIAS +9V) |
| Batteries | Two 1.5V AA (not included) |
| Battery Life | >7 hours (alkaline) (Depending on battery type and use pattern) |
| Receiver Dimensions | 209.8 mm (8.26 inch) W x 44 mm (1.73 inch) H x 169.3 mm (6.67 inch) D |
| Receiver Net Weight | 940 grams (33.2 oz) |
| Body-Pack Transmitter Dimensions | 70.2 mm (2.76 inch) W x 107.0 mm (4.21 inch) H x 24.9 mm (0.98 inch) D |
| Body-Pack Transmitter Net Weight | 100 grams (3.5 oz) without batteries |
| Handheld Transmitter Dimensions | 254.8 mm (10.03 inch) long, 50.0 mm (1.97 inch) diameter |
| Handheld Transmitter Net Weight | 280 grams (9.9 oz) without batteries |
| Aggregate | x |
Why Buy the Audio-Technica ATW-1322 Dual Channel Dynamic Handheld Microphone Rack from Trianze Tech?
- Genuine Audio-Technica product sourced through authorized channels with local UAE support
- Pre-sales help matching the ATW-1322 to your microphones, mixers and installation
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Procurement-ready quotations for venues, broadcasters, schools and corporate projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The Audio-Technica ATW-1322 has a frequency response of 20 Hz to 20 kHz (Depending on microphone type).
Published specifications give an operating range of 60 m (200') (Open range environment with no interfering signals) for the Audio-Technica ATW-1322.
Published specifications list battery life for the Audio-Technica ATW-1322 as >7 hours (alkaline) (Depending on battery type and use pattern).
The RF power output of the Audio-Technica ATW-1322 is 10 mW. Check local wireless regulation before use in the UAE.
Published specifications list the weight of the Audio-Technica ATW-1322 as 940 grams (33.2 oz).
Trianze Tech stocks the Audio-Technica ATW-1322 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
