Allen & Heath DX88-P: 8 In x 8 Out 96 kHz DX Expander with Phoenix Euroblock Connectors for AHM Matrix Processors
Model
:
DX88-P
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Call for Best Price: +971 58 161 3661 | Chat on WhatsApp
Allen & Heath DX88-P 8 In x 8 Out 96 kHz Expander
The Allen & Heath DX88-P provides 8 inputs and 8 outputs on Phoenix / Euroblock connectors for fixed installations, and is an easy way to add local or remote expansion to AHM audio matrix processors. It is a 96 kHz DX expander for placing 8 mic/line inputs and 8 line outputs wherever extra analog audio is needed, up to 100 m from the mixer. It connects over a single Cat5e cable to the mixer or an upstream DX expander on the DX A port, with a DX B port for daisy chaining to a downstream expander. Trianze Tech supplies the DX88-P across Dubai, Abu Dhabi, the UAE and GCC.
Key Features:
- 8 mic/line inputs and 8 line outputs
- Phoenix / Euroblock connectors
- 96 kHz operation
- Up to 100 m from the mixer on a single Cat5e cable
- DX A port and DX B port for daisy chaining
- Optional rack kit for up to two units in 1U
Technical Specifications:
| Spec | Value |
|---|---|
| Model | DX88-P Expander |
| Type | DX expander for fixed installation |
| Inputs | 8 mic/line |
| Outputs | 8 line |
| Connectors | Phoenix / Euroblock |
| Sampling Rate | 96 kHz |
| Distance | Up to 100 m on Cat5e |
| Ports | DX A and DX B (RJ45) |
| Rack Option | Up to two units in a 1U 19 inch slot (optional kit) |
Why Buy the Allen & Heath DX88-P from Trianze Tech?
- Genuine Allen & Heath equipment sourced through authorized channels with local UAE support
- Pre-sales help matching the DX88-P to your console, stage boxes and network
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Procurement-ready quotations for live sound, installation, worship and corporate projects
Frequently asked
Questions our clients ask before signing.
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant — most queries are answered in a 15-minute call.
The DX88-P is a 96 kHz DX expander with 8 mic/line inputs and 8 line outputs on Phoenix / Euroblock connectors for fixed installations.
It can be placed up to 100 m from the mixer, connected over a single Cat5e cable.
Yes. The DX A port connects to the mixer or an upstream DX expander, and the DX B port connects to a downstream DX expander for more remote I/O.
Yes. An optional rack mount kit holds up to two DX88-P units in a 1U 19 inch slot, and it can share a rack with a DX Hub or GPIO module using the combined kits.
It is designed to add local or remote expansion to AHM audio matrix processors. Trianze Tech confirms other compatible systems at order.
Trianze Tech supplies the Allen & Heath DX88-P in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
