Electro-Voice EVOLVE 70: Column System (Subwoofer Only), Black
Genuine Products
Original Brand Warranty
Product Training
Installation, Maintenance & Support
Electro-Voice EVOLVE 70 at a Glance
- Brand
- Electro-Voice
- Model
- EVOLVE 70
- SKU
- 148030
- Category
- Subwoofers
- Solution
- Boardroom AV
- Supply
- Dubai, Abu Dhabi and across the UAE
- Pricing
- Quoted per project
Applications & Use Cases
Electro-Voice EVOLVE 70 Overview
The EVOLVE 70 Column Loudspeaker System is a powerful yet portable addition to the EVOLVE family. It has been designed to bring impeccable audio quality and extreme output alongside ease of use and portability to professionals looking to cover larger gigs. Supplied by Trianze Tech to projects in Dubai, Abu Dhabi and across the UAE and GCC.
Key Features:
- The EVOLVE family is a proven leader in portability and the EVOLVE 70 follows this tradition.
- Advanced materials combined with ergonomic design principles have been used throughout the system, ensuring that the acoustic performance exceeds customer expectations while also being the lightest and most portable model in its class.
- Frequency response low (-3 dB) (Hz): 40 Hz
- Frequency response high (-3 dB) (Hz): 18000 Hz
- Frequency Response: 40 Hz, 18,000 Hz
- Amplifier Watt Peak: 2000 W
Technical Specifications:
| Spec | Value |
|---|---|
| Model | EVOLVE 70 |
| Brand | Electro-Voice |
| Frequency response low (-3 dB) (Hz) | 40 Hz |
| Frequency response high (-3 dB) (Hz) | 18000 Hz |
| Frequency Response | 40 Hz, 18,000 Hz |
| Amplifier Watt Peak | 2000 W |
| Color | Black or white |
| Enclosure | Plywood with polyurea coating (subwoofer) Composite (column) Aluminum (pole) |
| Grille | Steel with black or white powder coat |
| Net weight | 35.5 kg |
| Shipping Weight | 72.8 lb (subwoofer) 25.1 lb (column and pole) |
| Max SPL | 134 dB |
| Frequency Range (-10 dB) | 28 Hz, 20,000 Hz |
| Total Output Power | 2000 W |
| Phantom Power | Yes |
| LF power handling (continuous) (W) | 500 W |
| HF power handling (continuous) (W) | 500 W |
| Power consumption (W) | 100-240 V AC, 50-60 Hz, 1.5-0.6 A |
| Dimensions (H x W x D) (mm) | Sub: 448 x 332 x 432 |
| LF transducer size (in) | 12-inch woofer |
| HF transducer size (in) | 3.5-inch neodymium drivers (8) |
| Operating Voltage / Power | 100 to 240 VAC, 50 to 60 Hz, 1.0 to 0.5 A |
| Dimensions (H x W x D) (in) | 82.40 x 13.54 x 18.50 |
Why Buy the Electro-Voice EVOLVE 70 from Trianze Tech?
- Genuine Electro-Voice product supplied by Trianze Tech with local UAE support
- Pre-sales help designing the audio system around the EVOLVE 70
- Fast delivery across Dubai, Abu Dhabi, the wider UAE and the GCC
- Installation advice for venues, houses of worship and corporate spaces
What's Included and Support
Frequently asked
Electro-Voice EVOLVE 70: Frequently Asked Questions
If you don't see your question here, our consultants will gladly walk you through specifics on a discovery call.
Still have questions?
Talk to a consultant. Most queries are answered in a 15-minute call.
The EVOLVE 70 Column Loudspeaker System is a powerful yet portable addition to the EVOLVE family. It has been designed to bring impeccable audio quality and extreme output alongside ease of use and portability to professionals looking to cover larger gigs.
For the Electro-Voice EVOLVE 70, Electro-Voice lists the following. Frequency Response: 40 Hz, 18,000 Hz; Amplifier Watt Peak: 2000 W; Max SPL: 134 dB; LF power handling (continuous) (W): 500 W; HF power handling (continuous) (W): 500 W.
For the Electro-Voice EVOLVE 70, Electro-Voice lists the following. Amplifier Watt Peak: 2000 W; Total Output Power: 2000 W; Phantom Power: Yes; LF power handling (continuous) (W): 500 W.
For the Electro-Voice EVOLVE 70, Electro-Voice lists the following. Color: Black or white; Enclosure: Plywood with polyurea coating (subwoofer) Composite (column) Aluminum (pole); Net weight: 35.5 kg; Shipping Weight: 72.8 lb (subwoofer) 25.1 lb (column and pole); Dimensions (H x W x D) (mm): Sub: 448 x 332 x 432.
The model is EVOLVE 70. Quote this model when you call or message Trianze Tech so we match the exact product and version.
Trianze Tech stocks the Electro-Voice EVOLVE 70 in Dubai with fast delivery across the UAE and GCC. Call +971 58 161 3661 or message us on WhatsApp for the best price and current stock availability.
